Avoid libwebp Electron Woes On macOS With positron

If you’ve got 👀 on this blog (directly, or via syndication) you’d have to have been living under a rock to not know about the libwebp supply chain disaster. An unfortunate casualty of inept programming just happened to be any app in the Electron ecosystem that doesn’t undergo bleeding-edge updates.

Former cow-orker Tom Sellers (one of the best humans in cyber) did a great service to the macOS user community with tips on how to stay safe on macOS. His find + strings + grep combo was superbly helpful and I hope many macOS users did the command line dance to see how negligent their app providers were/are.

But, you still have to know what versions are OK and which ones are not to do that dance. And, having had yet-another immune system invasion (thankfully, not COVID, again) on top of still working through long COVID (#protip: you may be over the pandemic, but I guarantee it’s not done with you/us for a while) which re-sapped mobility energy, I put my sedentary time to less woesome use by hacking together a small, Golang macOS CLI to help ferret out bad Electron-based apps you may have installed.

I named it positron, since that’s kind of the opposite of Electron, and I was pretty creativity-challenged today.

It does virtually the same thing as Tom’s strings and grep does, just in a single, lightweight, universal, signed macOS binary.

When I ran it after the final build, all my Electron-based apps were 🔴. After deleting some, and updating others, this is my current status:

$ find /Applications -type f -name "*Electron Framework*" -exec ./positron "{}" \;
/Applications/Signal.app: Chrome/114.0.5735.289 Electron/25.8.4 🟢
/Applications/Keybase.app: Chrome/87.0.4280.141 Electron/11.5.0 🔴
/Applications/Raindrop.io.app: Chrome/102.0.5005.167 Electron/19.0.17 🔴
/Applications/1Password.app: Chrome/114.0.5735.289 Electron/25.8.1 🟢
/Applications/Replit.app: Chrome/116.0.5845.188 Electron/26.2.1 🟢
/Applications/lghub.app: Chrome/104.0.5112.65 Electron/20.0.0 🔴

It’s still on you to do the find (cooler folks run fd) since I’m not about to write a program that’ll rummage across your SSDs or disc drives, but it does all the MachO inspection internally, and then also does the SemVer comparison to let you know which apps still suck at keeping you safe.

FWIW, the Keybase folks did accept a PR for the libwebp thing, but darned if I will spend any time building it (I don’t run it anymore, anyway, so I should just delete it).

The aforementioned signed, universal, macOS binary is in the GitLab releases.

Stay safe out there!

Acoustic: Solving a CyberDefenders PCAP SIP/RTP Challenge with R, Zeek, tshark (& friends)

Hot on the heels of the previous CyberDefenders Challenge Solution comes this noisy installment which solves their Acoustic challenge.

You can find the source Rmd on GitHub, but I’m also testing the limits of WP’s markdown rendering and putting it in-stream as well.

No longer book expository this time since much of the setup/explanatory bits from it apply here as well).

Acoustic

This challenge takes us “into the world of voice communications on the internet. VoIP is becoming the de-facto standard for voice communication. As this technology becomes more common, malicious parties have more opportunities and stronger motives to control these systems to conduct nefarious activities. This challenge was designed to examine and explore some of the attributes of the SIP and RTP protocols.”

We have two files to work with:

  • log.txt which was generated from an unadvertised, passive honeypot located on the internet such that any traffic destined to it must be nefarious. Unknown parties scanned the honeypot with a range of tools, and this activity is represented in the log file.
    • The IP address of the honeypot has been changed to “honey.pot.IP.removed”. In terms of geolocation, pick your favorite city.
    • The MD5 hash in the authorization digest is replaced with “MD5_hash_removedXXXXXXXXXXXXXXXX”
    • Some octets of external IP addresses have been replaced with an “X”
    • Several trailing digits of phone numbers have been replaced with an “X”
    • Assume the timestamps in the log files are UTC.
  • Voip-trace.pcap was created by honeynet members for this forensic challenge to allow participants to employ network analysis skills in the VOIP context.

There are 14 questions to answer.

If you are not familiar with SIP and/or RTP you should do a bit of research first. A good place to start is RTC 3261 (for SIP) and RFC 3550 (for RTC). Some questions may be able to be answered just by knowing the details of these protocols.

Convert the PCAP

library(stringi)
library(tidyverse)

We’ll pre-generate Zeek logs. The -C tells Zeek to not bother with checksums, -r tells it to read from a file and the LogAscii::use_json=T means we want JSON output vs the default delimited files. JSON gives us data types (the headers in the delimited files do as well, but we’d have to write something to read those types then deal with it vs get this for free out of the box with JSON).

system("ZEEK_LOG_SUFFIX=json /opt/zeek/bin/zeek -C -r src/Voip-trace.pcap LogAscii::use_json=T HTTP::default_capture_password=T")

We process the PCAP twice with tshark. Once to get the handy (and small) packet summary table, then dump the whole thing to JSON. We may need to run tshark again down the road a bit.

system("tshark -T tabs -r src/Voip-trace.pcap > voip-packets.tsv")
system("tshark -T json -r src/Voip-trace.pcap > voip-trace")

Examine and Process log.txt

We aren’t told what format log.txt is in, so let’s take a look:

cd_sip_log <- stri_read_lines("src/log.txt")

cat(head(cd_sip_log, 25), sep="\n")
## Source: 210.184.X.Y:1083
## Datetime: 2010-05-02 01:43:05.606584
##
## Message:
##
## OPTIONS sip:100@honey.pot.IP.removed SIP/2.0
## Via: SIP/2.0/UDP 127.0.0.1:5061;branch=z9hG4bK-2159139916;rport
## Content-Length: 0
## From: "sipvicious"<sip:100@1.1.1.1>; tag=X_removed
## Accept: application/sdp
## User-Agent: friendly-scanner
## To: "sipvicious"<sip:100@1.1.1.1>
## Contact: sip:100@127.0.0.1:5061
## CSeq: 1 OPTIONS
## Call-ID: 845752980453913316694142
## Max-Forwards: 70
##
##
##
##
## -------------------------
## Source: 210.184.X.Y:4956
## Datetime: 2010-05-02 01:43:12.488811
##
## Message:

These look a bit like HTTP server responses, but we know we’re working in SIP land and if you perused the RFC you’d have noticed that SIP is an HTTP-like ASCII protocol. While some HTTP response parsers might work on these records, it’s pretty straightforward to whip up a bespoke pseudo-parser.

Let’s see how many records there are by counting the number of “Message:” lines (we’re doing this, primarily, to see if we should use the {furrr} package to speed up processing):

cd_sip_log[stri_detect_fixed(cd_sip_log, "Message:")] %>%
  table()
## .
## Message:
##     4266

There are many, so we’ll avoid parallel processing the data and just use a single thread.

One way to tackle the parsing is to look for the stop and start of each record, extract fields (these have similar formats to HTTP headers), and perhaps have to extract content as well. We know this because there are “Content-Length:” fields. According to the RFC they are supposed to exist for every message. Let’s first see if any “Content-Length:” header records are greater than 0. We’ll do this with a little help from the ripgrep utility as it provides a way to see context before and/or after matched patterns:

cat(system('rg --after-context=10 "^Content-Length: [^0]" src/log.txt', intern=TRUE), sep="\n")
## Content-Length: 330
##
## v=0
## o=Zoiper_user 0 0 IN IP4 89.42.194.X
## s=Zoiper_session
## c=IN IP4 89.42.194.X
## t=0 0
## m=audio 52999 RTP/AVP 3 0 8 110 98 101
## a=rtpmap:3 GSM/8000
## a=rtpmap:0 PCMU/8000
## a=rtpmap:8 PCMA/8000
## --
## Content-Length: 330
##
## v=0
## o=Zoiper_user 0 0 IN IP4 89.42.194.X
## s=Zoiper_session
## c=IN IP4 89.42.194.X
## t=0 0
## m=audio 52999 RTP/AVP 3 0 8 110 98 101
## a=rtpmap:3 GSM/8000
## a=rtpmap:0 PCMU/8000
## a=rtpmap:8 PCMA/8000
## --
## Content-Length: 330
##
## v=0
## o=Zoiper_user 0 0 IN IP4 89.42.194.X
## s=Zoiper_session
## c=IN IP4 89.42.194.X
## t=0 0
## m=audio 52999 RTP/AVP 3 0 8 110 98 101
## a=rtpmap:3 GSM/8000
## a=rtpmap:0 PCMU/8000
## a=rtpmap:8 PCMA/8000
## --
## Content-Length: 330
##
## v=0
## o=Zoiper_user 0 0 IN IP4 89.42.194.X
## s=Zoiper_session
## c=IN IP4 89.42.194.X
## t=0 0
## m=audio 52999 RTP/AVP 3 0 8 110 98 101
## a=rtpmap:3 GSM/8000
## a=rtpmap:0 PCMU/8000
## a=rtpmap:8 PCMA/8000

So,we do need to account for content. It’s still pretty straightforward (explanatory comments inline):

starts <- which(stri_detect_regex(cd_sip_log, "^Source:"))
stops <- which(stri_detect_regex(cd_sip_log, "^----------"))

map2_dfr(starts, stops, ~{

  raw_rec <- stri_trim_both(cd_sip_log[.x:.y]) # target the record from the log
  raw_rec <- raw_rec[raw_rec != "-------------------------"] # remove separator

  msg_idx <- which(stri_detect_regex(raw_rec, "^Message:")) # find where "Message:" line is
  source_idx <- which(stri_detect_regex(raw_rec, "^Source: ")) # find where "Source:" line is
  datetime_idx <- which(stri_detect_regex(raw_rec, "^Datetime: ")) # find where "Datetime:" line is
  contents_idx <- which(stri_detect_regex(raw_rec[(msg_idx+2):length(raw_rec)], "^$"))[1] + 2 # get position of the "data"

  source <- stri_match_first_regex(raw_rec[source_idx], "^Source: (.*)$")[,2] # extract source
  datetime <- stri_match_first_regex(raw_rec[datetime_idx], "^Datetime: (.*)$")[,2] # extract datetime
  request <- raw_rec[msg_idx+2] # extract request line

  # build a matrix out of the remaining headers. header key will be in column 2, value will be in column 3
  tmp <- stri_match_first_regex(raw_rec[(msg_idx+3):contents_idx], "^([^:]+):[[:space:]]+(.*)$")
  tmp[,2] <- stri_trans_tolower(tmp[,2]) # lowercase the header key
  tmp[,2] <- stri_replace_all_fixed(tmp[,2], "-", "_") # turn dashes to underscores so we can more easily use the keys as column names

  contents <- raw_rec[(contents_idx+1):length(raw_rec)]
  contents <- paste0(contents[contents != ""], collapse = "\n")

  as.list(tmp[,3]) %>% # turn the header values into a list
    set_names(tmp[,2]) %>% # make their names the tranformed keys
    append(c(
      source = source, # add source to the list (etc)
      datetime = datetime,
      request = request,
      contents = contents
    ))

}) -> sip_log_parsed

Let’s see what we have:

sip_log_parsed
## # A tibble: 4,266 x 18
##    via     content_length from    accept  user_agent to     contact cseq  source
##    <chr>   <chr>          <chr>   <chr>   <chr>      <chr>  <chr>   <chr> <chr>
##  1 SIP/2.… 0              "\"sip… applic… friendly-… "\"si… sip:10… 1 OP… 210.1…
##  2 SIP/2.… 0              "\"342… applic… friendly-… "\"34… sip:34… 1 RE… 210.1…
##  3 SIP/2.… 0              "\"172… applic… friendly-… "\"17… sip:17… 1 RE… 210.1…
##  4 SIP/2.… 0              "\"adm… applic… friendly-… "\"ad… sip:ad… 1 RE… 210.1…
##  5 SIP/2.… 0              "\"inf… applic… friendly-… "\"in… sip:in… 1 RE… 210.1…
##  6 SIP/2.… 0              "\"tes… applic… friendly-… "\"te… sip:te… 1 RE… 210.1…
##  7 SIP/2.… 0              "\"pos… applic… friendly-… "\"po… sip:po… 1 RE… 210.1…
##  8 SIP/2.… 0              "\"sal… applic… friendly-… "\"sa… sip:sa… 1 RE… 210.1…
##  9 SIP/2.… 0              "\"ser… applic… friendly-… "\"se… sip:se… 1 RE… 210.1…
## 10 SIP/2.… 0              "\"sup… applic… friendly-… "\"su… sip:su… 1 RE… 210.1…
## # … with 4,256 more rows, and 9 more variables: datetime <chr>, request <chr>,
## #   contents <chr>, call_id <chr>, max_forwards <chr>, expires <chr>,
## #   allow <chr>, authorization <chr>, content_type <chr>

glimpse(sip_log_parsed)
## Rows: 4,266
## Columns: 18
## $ via            <chr> "SIP/2.0/UDP 127.0.0.1:5061;branch=z9hG4bK-2159139916;r…
## $ content_length <chr> "0", "0", "0", "0", "0", "0", "0", "0", "0", "0", "0", …
## $ from           <chr> "\"sipvicious\"<sip:100@1.1.1.1>; tag=X_removed", "\"34…
## $ accept         <chr> "application/sdp", "application/sdp", "application/sdp"…
## $ user_agent     <chr> "friendly-scanner", "friendly-scanner", "friendly-scann…
## $ to             <chr> "\"sipvicious\"<sip:100@1.1.1.1>", "\"3428948518\"<sip:…
## $ contact        <chr> "sip:100@127.0.0.1:5061", "sip:3428948518@honey.pot.IP.…
## $ cseq           <chr> "1 OPTIONS", "1 REGISTER", "1 REGISTER", "1 REGISTER", …
## $ source         <chr> "210.184.X.Y:1083", "210.184.X.Y:4956", "210.184.X.Y:51…
## $ datetime       <chr> "2010-05-02 01:43:05.606584", "2010-05-02 01:43:12.4888…
## $ request        <chr> "OPTIONS sip:100@honey.pot.IP.removed SIP/2.0", "REGIST…
## $ contents       <chr> "Call-ID: 845752980453913316694142\nMax-Forwards: 70", …
## $ call_id        <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ max_forwards   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ expires        <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ allow          <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ authorization  <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ content_type   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…

Looks 👍, but IRL there are edge-cases we’d have to deal with.

Process Zeek Logs

Because they’re JSON files, and the names are reasonable, we can do some magic incantations to read them all in and shove them into a list we’ll call zeek:

zeek <- list()

list.files(
  pattern = "json$",
  full.names = TRUE
) %>%
  walk(~{
    append(zeek, list(file(.x) %>%
      jsonlite::stream_in(verbose = FALSE) %>%
      as_tibble()) %>%
        set_names(tools::file_path_sans_ext(basename(.x)))
    ) ->> zeek
  })

str(zeek, 1)
## List of 7
##  $ conn         : tibble [97 × 18] (S3: tbl_df/tbl/data.frame)
##  $ dpd          : tibble [1 × 9] (S3: tbl_df/tbl/data.frame)
##  $ files        : tibble [38 × 16] (S3: tbl_df/tbl/data.frame)
##  $ http         : tibble [92 × 24] (S3: tbl_df/tbl/data.frame)
##  $ packet_filter: tibble [1 × 5] (S3: tbl_df/tbl/data.frame)
##  $ sip          : tibble [9 × 23] (S3: tbl_df/tbl/data.frame)
##  $ weird        : tibble [1 × 9] (S3: tbl_df/tbl/data.frame)

walk2(names(zeek), zeek, ~{
  cat("File:", .x, "\n")
  glimpse(.y)
  cat("\n\n")
})
## File: conn
## Rows: 97
## Columns: 18
## $ ts            <dbl> 1272737631, 1272737581, 1272737669, 1272737669, 12727376…
## $ uid           <chr> "Cb0OAQ1eC0ZhQTEKNl", "C2s0IU2SZFGVlZyH43", "CcEeLRD3cca…
## $ id.orig_h     <chr> "172.25.105.43", "172.25.105.43", "172.25.105.43", "172.…
## $ id.orig_p     <int> 57086, 5060, 57087, 57088, 57089, 57090, 57091, 57093, 5…
## $ id.resp_h     <chr> "172.25.105.40", "172.25.105.40", "172.25.105.40", "172.…
## $ id.resp_p     <int> 80, 5060, 80, 80, 80, 80, 80, 80, 80, 80, 80, 80, 80, 80…
## $ proto         <chr> "tcp", "udp", "tcp", "tcp", "tcp", "tcp", "tcp", "tcp", …
## $ service       <chr> "http", "sip", "http", "http", "http", "http", "http", "…
## $ duration      <dbl> 0.0180180073, 0.0003528595, 0.0245900154, 0.0740420818, …
## $ orig_bytes    <int> 502, 428, 380, 385, 476, 519, 520, 553, 558, 566, 566, 5…
## $ resp_bytes    <int> 720, 518, 231, 12233, 720, 539, 17499, 144, 144, 144, 14…
## $ conn_state    <chr> "SF", "SF", "SF", "SF", "SF", "SF", "SF", "SF", "SF", "S…
## $ missed_bytes  <int> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,…
## $ history       <chr> "ShADadfF", "Dd", "ShADadfF", "ShADadfF", "ShADadfF", "S…
## $ orig_pkts     <int> 5, 1, 5, 12, 5, 6, 16, 6, 6, 5, 5, 5, 5, 5, 5, 5, 6, 5, …
## $ orig_ip_bytes <int> 770, 456, 648, 1017, 744, 839, 1360, 873, 878, 834, 834,…
## $ resp_pkts     <int> 5, 1, 5, 12, 5, 5, 16, 5, 5, 5, 5, 5, 5, 5, 5, 5, 5, 5, …
## $ resp_ip_bytes <int> 988, 546, 499, 12865, 988, 807, 18339, 412, 412, 412, 41…
##
##
## File: dpd
## Rows: 1
## Columns: 9
## $ ts             <dbl> 1272737798
## $ uid            <chr> "CADvMziC96POynR2e"
## $ id.orig_h      <chr> "172.25.105.3"
## $ id.orig_p      <int> 43204
## $ id.resp_h      <chr> "172.25.105.40"
## $ id.resp_p      <int> 5060
## $ proto          <chr> "udp"
## $ analyzer       <chr> "SIP"
## $ failure_reason <chr> "Binpac exception: binpac exception: string mismatch at…
##
##
## File: files
## Rows: 38
## Columns: 16
## $ ts             <dbl> 1272737631, 1272737669, 1272737676, 1272737688, 1272737…
## $ fuid           <chr> "FRnb7P5EDeZE4Y3z4", "FOT2gC2yLxjfMCuE5f", "FmUCuA3dzcS…
## $ tx_hosts       <list> "172.25.105.40", "172.25.105.40", "172.25.105.40", "17…
## $ rx_hosts       <list> "172.25.105.43", "172.25.105.43", "172.25.105.43", "17…
## $ conn_uids      <list> "Cb0OAQ1eC0ZhQTEKNl", "CFfYtA0DqqrJk4gI5", "CHN4qA4UUH…
## $ source         <chr> "HTTP", "HTTP", "HTTP", "HTTP", "HTTP", "HTTP", "HTTP",…
## $ depth          <int> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0…
## $ analyzers      <list> [], [], [], [], [], [], [], [], [], [], [], [], [], []…
## $ mime_type      <chr> "text/html", "text/html", "text/html", "text/html", "te…
## $ duration       <dbl> 0.000000e+00, 8.920908e-03, 0.000000e+00, 0.000000e+00,…
## $ is_orig        <lgl> FALSE, FALSE, FALSE, FALSE, FALSE, TRUE, FALSE, FALSE, …
## $ seen_bytes     <int> 479, 11819, 479, 313, 17076, 55, 50, 30037, 31608, 1803…
## $ total_bytes    <int> 479, NA, 479, 313, NA, 55, 50, NA, NA, NA, 58, 313, 50,…
## $ missing_bytes  <int> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0…
## $ overflow_bytes <int> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0…
## $ timedout       <lgl> FALSE, FALSE, FALSE, FALSE, FALSE, FALSE, FALSE, FALSE,…
##
##
## File: http
## Rows: 92
## Columns: 24
## $ ts                <dbl> 1272737631, 1272737669, 1272737669, 1272737676, 1272…
## $ uid               <chr> "Cb0OAQ1eC0ZhQTEKNl", "CcEeLRD3cca3j4QGh", "CFfYtA0D…
## $ id.orig_h         <chr> "172.25.105.43", "172.25.105.43", "172.25.105.43", "…
## $ id.orig_p         <int> 57086, 57087, 57088, 57089, 57090, 57091, 57093, 570…
## $ id.resp_h         <chr> "172.25.105.40", "172.25.105.40", "172.25.105.40", "…
## $ id.resp_p         <int> 80, 80, 80, 80, 80, 80, 80, 80, 80, 80, 80, 80, 80, …
## $ trans_depth       <int> 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1…
## $ method            <chr> "GET", "GET", "GET", "GET", "GET", "GET", "GET", "GE…
## $ host              <chr> "172.25.105.40", "172.25.105.40", "172.25.105.40", "…
## $ uri               <chr> "/maint", "/", "/user/", "/maint", "/maint", "/maint…
## $ referrer          <chr> "http://172.25.105.40/user/", NA, NA, "http://172.25…
## $ version           <chr> "1.1", "1.1", "1.1", "1.1", "1.1", "1.1", "1.1", "1.…
## $ user_agent        <chr> "Mozilla/5.0 (X11; U; Linux i686; en-US; rv:1.9.1.9)…
## $ request_body_len  <int> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0…
## $ response_body_len <int> 479, 0, 11819, 479, 313, 17076, 0, 0, 0, 0, 0, 0, 0,…
## $ status_code       <int> 401, 302, 200, 401, 301, 200, 304, 304, 304, 304, 30…
## $ status_msg        <chr> "Authorization Required", "Found", "OK", "Authorizat…
## $ tags              <list> [], [], [], [], [], [], [], [], [], [], [], [], [],…
## $ resp_fuids        <list> "FRnb7P5EDeZE4Y3z4", <NULL>, "FOT2gC2yLxjfMCuE5f", …
## $ resp_mime_types   <list> "text/html", <NULL>, "text/html", "text/html", "tex…
## $ username          <chr> NA, NA, NA, NA, "maint", "maint", "maint", "maint", …
## $ password          <chr> NA, NA, NA, NA, "password", "password", "password", …
## $ orig_fuids        <list> <NULL>, <NULL>, <NULL>, <NULL>, <NULL>, <NULL>, <NU…
## $ orig_mime_types   <list> <NULL>, <NULL>, <NULL>, <NULL>, <NULL>, <NULL>, <NU…
##
##
## File: packet_filter
## Rows: 1
## Columns: 5
## $ ts      <dbl> 1627151196
## $ node    <chr> "zeek"
## $ filter  <chr> "ip or not ip"
## $ init    <lgl> TRUE
## $ success <lgl> TRUE
##
##
## File: sip
## Rows: 9
## Columns: 23
## $ ts                <dbl> 1272737581, 1272737768, 1272737768, 1272737768, 1272…
## $ uid               <chr> "C2s0IU2SZFGVlZyH43", "CADvMziC96POynR2e", "CADvMziC…
## $ id.orig_h         <chr> "172.25.105.43", "172.25.105.3", "172.25.105.3", "17…
## $ id.orig_p         <int> 5060, 43204, 43204, 43204, 43204, 43204, 43204, 4320…
## $ id.resp_h         <chr> "172.25.105.40", "172.25.105.40", "172.25.105.40", "…
## $ id.resp_p         <int> 5060, 5060, 5060, 5060, 5060, 5060, 5060, 5060, 5060
## $ trans_depth       <int> 0, 0, 0, 0, 0, 0, 0, 0, 0
## $ method            <chr> "OPTIONS", "REGISTER", "REGISTER", "SUBSCRIBE", "SUB…
## $ uri               <chr> "sip:100@172.25.105.40", "sip:172.25.105.40", "sip:1…
## $ request_from      <chr> "\"sipvicious\"<sip:100@1.1.1.1>", "<sip:555@172.25.…
## $ request_to        <chr> "\"sipvicious\"<sip:100@1.1.1.1>", "<sip:555@172.25.…
## $ response_from     <chr> "\"sipvicious\"<sip:100@1.1.1.1>", "<sip:555@172.25.…
## $ response_to       <chr> "\"sipvicious\"<sip:100@1.1.1.1>;tag=as18cdb0c9", "<…
## $ call_id           <chr> "61127078793469957194131", "MzEwMmYyYWRiYTUxYTBhODY3…
## $ seq               <chr> "1 OPTIONS", "1 REGISTER", "2 REGISTER", "1 SUBSCRIB…
## $ request_path      <list> "SIP/2.0/UDP 127.0.1.1:5060", "SIP/2.0/UDP 172.25.10…
## $ response_path     <list> "SIP/2.0/UDP 127.0.1.1:5060", "SIP/2.0/UDP 172.25.10…
## $ user_agent        <chr> "UNfriendly-scanner - for demo purposes", "X-Lite B…
## $ status_code       <int> 200, 401, 200, 401, 404, 401, 100, 200, NA
## $ status_msg        <chr> "OK", "Unauthorized", "OK", "Unauthorized", "Not fo…
## $ request_body_len  <int> 0, 0, 0, 0, 0, 264, 264, 264, 0
## $ response_body_len <int> 0, 0, 0, 0, 0, 0, 0, 302, NA
## $ content_type      <chr> NA, NA, NA, NA, NA, NA, NA, "application/sdp", NA
##
##
## File: weird
## Rows: 1
## Columns: 9
## $ ts        <dbl> 1272737805
## $ id.orig_h <chr> "172.25.105.3"
## $ id.orig_p <int> 0
## $ id.resp_h <chr> "172.25.105.40"
## $ id.resp_p <int> 0
## $ name      <chr> "truncated_IPv6"
## $ notice    <lgl> FALSE
## $ peer      <chr> "zeek"
## $ source    <chr> "IP"

Process Packet Summary

We won’t process the big JSON file tshark generated for us util we really have to, but we can read in the packet summary table now:

packet_cols <- c("packet_num", "ts", "src", "discard", "dst", "proto", "length", "info")

read_tsv(
  file = "voip-packets.tsv",
  col_names = packet_cols,
  col_types = "ddccccdc"
) %>%
  select(-discard) -> packets

packets
## # A tibble: 4,447 x 7
##    packet_num       ts src      dst     proto length info
##         <dbl>    <dbl> <chr>    <chr>   <chr>  <dbl> <chr>
##  1          1  0       172.25.… 172.25… SIP      470 Request: OPTIONS sip:100@1…
##  2          2  3.53e-4 172.25.… 172.25… SIP      560 Status: 200 OK |
##  3          3  5.03e+1 172.25.… 172.25… TCP       74 57086 → 80 [SYN] Seq=0 Win…
##  4          4  5.03e+1 172.25.… 172.25… TCP       74 80 → 57086 [SYN, ACK] Seq=…
##  5          5  5.03e+1 172.25.… 172.25… TCP       66 57086 → 80 [ACK] Seq=1 Ack…
##  6          6  5.03e+1 172.25.… 172.25… HTTP     568 GET /maint HTTP/1.1
##  7          7  5.03e+1 172.25.… 172.25… TCP       66 80 → 57086 [ACK] Seq=1 Ack…
##  8          8  5.03e+1 172.25.… 172.25… HTTP     786 HTTP/1.1 401 Authorization…
##  9          9  5.03e+1 172.25.… 172.25… TCP       66 80 → 57086 [FIN, ACK] Seq=…
## 10         10  5.03e+1 172.25.… 172.25… TCP       66 57086 → 80 [ACK] Seq=503 A…
## # … with 4,437 more rows

glimpse(packets)
## Rows: 4,447
## Columns: 7
## $ packet_num <dbl> 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, …
## $ ts         <dbl> 0.000000, 0.000353, 50.317176, 50.317365, 50.320071, 50.329…
## $ src        <chr> "172.25.105.43", "172.25.105.40", "172.25.105.43", "172.25.…
## $ dst        <chr> "172.25.105.40", "172.25.105.43", "172.25.105.40", "172.25.…
## $ proto      <chr> "SIP", "SIP", "TCP", "TCP", "TCP", "HTTP", "TCP", "HTTP", "…
## $ length     <dbl> 470, 560, 74, 74, 66, 568, 66, 786, 66, 66, 66, 66, 74, 74,…
## $ info       <chr> "Request: OPTIONS sip:100@172.25.105.40 |", "Status: 200 OK…

What is the transport protocol being used?

SIP can use TCP or UDP and which transport it uses will be specified in the Via: header. Let’s take a look:

head(sip_log_parsed$via)
## [1] "SIP/2.0/UDP 127.0.0.1:5061;branch=z9hG4bK-2159139916;rport"
## [2] "SIP/2.0/UDP 127.0.0.1:5087;branch=z9hG4bK-1189344537;rport"
## [3] "SIP/2.0/UDP 127.0.0.1:5066;branch=z9hG4bK-2119091576;rport"
## [4] "SIP/2.0/UDP 127.0.0.1:5087;branch=z9hG4bK-3226446220;rport"
## [5] "SIP/2.0/UDP 127.0.0.1:5087;branch=z9hG4bK-1330901245;rport"
## [6] "SIP/2.0/UDP 127.0.0.1:5087;branch=z9hG4bK-945386205;rport"

Are they all UDP? We can find out by performing some light processing
on the via column:

sip_log_parsed %>%
  select(via) %>%
  mutate(
    transport = stri_match_first_regex(via, "^([^[:space:]]+)")[,2]
  ) %>%
  count(transport, sort=TRUE)
## # A tibble: 1 x 2
##   transport       n
##   <chr>       <int>
## 1 SIP/2.0/UDP  4266

Looks like they’re all UDP. Question 1: ✅

The attacker used a bunch of scanning tools that belong to the same suite. Provide the name of the suite.

Don’t you, now, wish you had listen to your parents when they were telling you about the facts of SIP life when you were a wee pup?

We’ll stick with the SIP log to answer this one and peek back at the RFC to see that there’s a “User-Agent:” field which contains information about the client originating the request. Most scanners written by defenders identify themselves in User-Agent fields when those fields are available in a protocol exchange, and a large percentage of naive malicious folks are too daft to change this value (or leave it default to make you think they’re not behaving badly).

If you are a regular visitor to SIP land, you likely know the common SIP scanning tools. These are a few:

  • Nmap’s SIP library
  • Mr.SIP, a “SIP-Based Audit and Attack Tool”
  • SIPVicious, a “set of security tools that can be used to audit SIP based VoIP systems”
  • Sippts, a “set of tools to audit SIP based VoIP Systems”

(There are many more.)

Let’s see what user-agent was used in this log extract:

count(sip_log_parsed, user_agent, sort=TRUE)
## # A tibble: 3 x 2
##   user_agent           n
##   <chr>            <int>
## 1 friendly-scanner  4248
## 2 Zoiper rev.6751     14
## 3 <NA>                 4

The overwhelming majority are friendly-scanner. Let’s look at a few of those log entries:

sip_log_parsed %>%
  filter(
    user_agent == "friendly-scanner"
  ) %>%
  glimpse()
## Rows: 4,248
## Columns: 18
## $ via            <chr> "SIP/2.0/UDP 127.0.0.1:5061;branch=z9hG4bK-2159139916;r…
## $ content_length <chr> "0", "0", "0", "0", "0", "0", "0", "0", "0", "0", "0", …
## $ from           <chr> "\"sipvicious\"<sip:100@1.1.1.1>; tag=X_removed", "\"34…
## $ accept         <chr> "application/sdp", "application/sdp", "application/sdp"…
## $ user_agent     <chr> "friendly-scanner", "friendly-scanner", "friendly-scann…
## $ to             <chr> "\"sipvicious\"<sip:100@1.1.1.1>", "\"3428948518\"<sip:…
## $ contact        <chr> "sip:100@127.0.0.1:5061", "sip:3428948518@honey.pot.IP.…
## $ cseq           <chr> "1 OPTIONS", "1 REGISTER", "1 REGISTER", "1 REGISTER", …
## $ source         <chr> "210.184.X.Y:1083", "210.184.X.Y:4956", "210.184.X.Y:51…
## $ datetime       <chr> "2010-05-02 01:43:05.606584", "2010-05-02 01:43:12.4888…
## $ request        <chr> "OPTIONS sip:100@honey.pot.IP.removed SIP/2.0", "REGIST…
## $ contents       <chr> "Call-ID: 845752980453913316694142\nMax-Forwards: 70", …
## $ call_id        <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ max_forwards   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ expires        <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ allow          <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ authorization  <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…
## $ content_type   <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA, NA,…

Those from and to fields have an interesting name in them: “sipviscious”. You’ve seen that before, right at the beginning of this section.

Let’s do a quick check over at the SIPvicious repo just to make sure.

count(sip_log_parsed, user_agent)
## # A tibble: 3 x 2
##   user_agent           n
##   <chr>            <int>
## 1 friendly-scanner  4248
## 2 Zoiper rev.6751     14
## 3 <NA>                 4

“What is the User-Agent of the victim system?”

We only have partial data in the text log so we’ll have to look elsewhere (the PCAP) for this information. The “victim” is whatever was the target of a this SIP-based attack and we can look for SIP messages, user agents, and associated IPs in the PCAP thanks to tshark’s rich SIP filter library:

system("tshark -Q -T fields -e ip.src -e ip.dst -e sip.User-Agent -r src/Voip-trace.pcap 'sip.User-Agent'")

That first exchange is all we really need. We see our rude poker talking to 172.25.105.40 and it responding right after.

Which tool was only used against the following extensions: 100, 101, 102, 103, and 111?

The question is a tad vague and is assuming — since we now know the SIPvicious suite was used — that we also know to provide the name of the Python script in SIPvicious that was used. There are five tools:

The svcrash tool is something defenders can use to help curtail scanner activity. We can cross that off the list. The svreport tool is for working with data generated by svmap, svwar and/or svcrack. One more crossed off. We also know that the attacker scanned the SIP network looking for nodes, which means svmap and svwar are likely not exclusive tool to the target extensions. (We technically have enough information right now to answer the question especially if you look carefully at the answer box on the site but that’s cheating).

The SIP request line and header field like “To:” destination information in the form of a SIP URI. Since we only care about the extension component of the URI for this question, we can use a regular expression to isolate them.

Back to the SIP log to see if we can find the identified extensions. We’ll also process the “From:” header just in case we need it.

sip_log_parsed %>%
  mutate_at(
    vars(request, from, to),
    ~stri_match_first_regex(.x, "sip:([^@]+)@")[,2]
  ) %>%
  select(request, from, to)
## # A tibble: 4,266 x 3
##    request    from       to
##    <chr>      <chr>      <chr>
##  1 100        100        100
##  2 3428948518 3428948518 3428948518
##  3 1729240413 1729240413 1729240413
##  4 admin      admin      admin
##  5 info       info       info
##  6 test       test       test
##  7 postmaster postmaster postmaster
##  8 sales      sales      sales
##  9 service    service    service
## 10 support    support    support
## # … with 4,256 more rows

That worked! We can now see what friendly-scanner attempted to authenticate only to our targets:

sip_log_parsed %>%
  mutate_at(
    vars(request, from, to),
    ~stri_match_first_regex(.x, "sip:([^@]+)@")[,2]
  ) %>%
  filter(
    user_agent == "friendly-scanner",
    stri_detect_fixed(contents, "Authorization")
  ) %>%
  distinct(to)
## # A tibble: 4 x 1
##   to
##   <chr>
## 1 102
## 2 103
## 3 101
## 4 111

While we’re missing 100 that’s likely due to it not requiring authentication (svcrack will REGISTER first to determine if a target requires authentication and not send cracking requests if it doesn’t).

Which extension on the honeypot does NOT require authentication?

We know this due to what we found in the previous question. Extension 100 does not require authentication.

How many extensions were scanned in total?

We just need to count the distinct to’s where the user agent is the scanner:

sip_log_parsed %>%
  mutate_at(
    vars(request, from, to),
    ~stri_match_first_regex(.x, "sip:([^@]+)@")[,2]
  ) %>%
  filter(
    user_agent == "friendly-scanner"
  ) %>%
  distinct(to)
## # A tibble: 2,652 x 1
##    to
##    <chr>
##  1 100
##  2 3428948518
##  3 1729240413
##  4 admin
##  5 info
##  6 test
##  7 postmaster
##  8 sales
##  9 service
## 10 support
## # … with 2,642 more rows

There is a trace for a real SIP client. What is the corresponding user-agent? (two words, once space in between)

We only need to look for user agent’s that aren’t our scanner:

sip_log_parsed %>%
  filter(
    user_agent != "friendly-scanner"
  ) %>%
  count(user_agent)
## # A tibble: 1 x 2
##   user_agent          n
##   <chr>           <int>
## 1 Zoiper rev.6751    14

Multiple real-world phone numbers were dialed. Provide the first 11 digits of the number dialed from extension 101?

Calls are “INVITE” requests

sip_log_parsed %>%
  mutate_at(
    vars(from, to),
    ~stri_match_first_regex(.x, "sip:([^@]+)@")[,2]
  ) %>%
  filter(
    from == 101,
    stri_detect_regex(cseq, "INVITE")
  ) %>%
  select(to)
## # A tibble: 3 x 1
##   to
##   <chr>
## 1 900114382089XXXX
## 2 00112322228XXXX
## 3 00112524021XXXX

The challenge answer box provides hint to what number they want. I’m not sure but I suspect it may be randomized, so you’ll have to match the pattern they expect with the correct digits above.

What are the default credentials used in the attempted basic authentication? (format is username:password)

This question wants us to look at the HTTP requests that require authentication. We can get he credentials info from the zeek$http log:

zeek$http %>%
  distinct(username, password)
## # A tibble: 2 x 2
##   username password
##   <chr>    <chr>
## 1 <NA>     <NA>
## 2 maint    password

Which codec does the RTP stream use? (3 words, 2 spaces in between)

“Codec” refers to the algorithm used to encode/decode an audio or video stream. The RTP RFC uses the term “payload type” to refer to this during exchanges and even has a link to RFC 3551 which provides further information on these encodings.

The summary packet table that tshark generates helpfully provides summary info for RTP packets and part of that info is PT=… which indicates the payload type.

packets %>%
  filter(proto == "RTP") %>%
  select(info)
## # A tibble: 2,988 x 1
##    info
##    <chr>
##  1 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6402, Time=126160
##  2 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6403, Time=126320
##  3 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6404, Time=126480
##  4 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6405, Time=126640
##  5 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6406, Time=126800
##  6 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6407, Time=126960
##  7 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6408, Time=127120
##  8 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6409, Time=127280
##  9 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6410, Time=127440
## 10 PT=ITU-T G.711 PCMU, SSRC=0xA254E017, Seq=6411, Time=127600
## # … with 2,978 more rows

How long is the sampling time (in milliseconds)?

  • 1 Hz = 1,000 ms
  • 1 ms = 1,000 Hz

(1/8000) * 1000

What was the password for the account with username 555?

We don’t really need to use external programs for this but it will sure go quite a bit faster if we do. While the original reference page for sipdump and sipcrack is defunct, you can visit that link to go to the Wayback machine’s capture of it. It will help if you have a linux system handy (so Docker to the rescue for macOS and Windows folks) since the following answer details are running on Ubunbu.

This question is taking advantage of the fact that the default authentication method for SIP is extremely weak. The process uses an MD5 challenge/response, and if an attacker can capture call traffic it is possible to brute force the password offline (which is what we’ll use sipcrack for).

You can install them via sudo apt install sipcrack.

We’ll first generate a dump of the authentication attempts with sipdump:

system("sipdump -p src/Voip-trace.pcap sip.dump", intern=TRUE)
##  [1] ""
##  [2] "SIPdump 0.2 "
##  [3] "---------------------------------------"
##  [4] ""
##  [5] "* Using pcap file 'src/Voip-trace.pcap' for sniffing"
##  [6] "* Starting to sniff with packet filter 'tcp or udp'"
##  [7] ""
##  [8] "* Dumped login from 172.25.105.40 -> 172.25.105.3 (User: '555')"
##  [9] "* Dumped login from 172.25.105.40 -> 172.25.105.3 (User: '555')"
## [10] "* Dumped login from 172.25.105.40 -> 172.25.105.3 (User: '555')"
## [11] ""
## [12] "* Exiting, sniffed 3 logins"

cat(readLines("sip.dump"), sep="\n")
## 172.25.105.3"172.25.105.40"555"asterisk"REGISTER"sip:172.25.105.40"4787f7ce""""MD5"1ac95ce17e1f0230751cf1fd3d278320
## 172.25.105.3"172.25.105.40"555"asterisk"INVITE"sip:1000@172.25.105.40"70fbfdae""""MD5"aa533f6efa2b2abac675c1ee6cbde327
## 172.25.105.3"172.25.105.40"555"asterisk"BYE"sip:1000@172.25.105.40"70fbfdae""""MD5"0b306e9db1f819dd824acf3227b60e07

It saves the IPs, caller, authentication realm, method, nonce and hash which will all be fed into the sipcrack.

We know from the placeholder answer text that the “password” is 4 characters, and this is the land of telephony, so we can make an assumption that it is really 4 digits. sipcrack needs a file of passwords to try, so We’ll let R make a randomized file of 4 digit pins for us:

cat(sprintf("%04d", sample(0:9999)), file = "4-digits", sep="\n")

We only have authenticaton packets for 555 so we can automate what would normally be an interactive process:

cat(system('echo "1" | sipcrack -w 4-digits sip.dump', intern=TRUE), sep="\n")
##
## SIPcrack 0.2
## ----------------------------------------
##
## * Found Accounts:
##
## Num  Server      Client      User    Hash|Password
##
## 1    172.25.105.3    172.25.105.40   555 1ac95ce17e1f0230751cf1fd3d278320
## 2    172.25.105.3    172.25.105.40   555 aa533f6efa2b2abac675c1ee6cbde327
## 3    172.25.105.3    172.25.105.40   555 0b306e9db1f819dd824acf3227b60e07
##
## * Select which entry to crack (1 - 3):
## * Generating static MD5 hash... c3e0f1664fde9fbc75a7cbd341877875
## * Loaded wordlist: '4-digits'
## * Starting bruteforce against user '555' (MD5: '1ac95ce17e1f0230751cf1fd3d278320')
## * Tried 8904 passwords in 0 seconds
##
## * Found password: '1234'
## * Updating dump file 'sip.dump'... done

Which RTP packet header field can be used to reorder out of sync RTP packets in the correct sequence?

Just reading involved here: 5.1 RTP Fixed Header Fields.

The trace includes a secret hidden message. Can you hear it?

We could command line this one but honestly Wireshark has a pretty keen audio player. Fire it up, open up the PCAP, go to the “Telephony” menu, pick SIP and play the streams.

Packet Maze: Solving a CyberDefenders PCAP Puzzle with R, Zeek, and tshark

It was a rainy weekend in southern Maine and I really didn’t feel like doing chores, so I was skimming through RSS feeds and noticed a link to a PacketMaze challenge in the latest This Week In 4n6.

Since it’s also been a while since I’ve done any serious content delivery (on the personal side, anyway), I thought it’d be fun to solve the challenge with some tools I like — namely Zeek, tshark, and R (links to those in the e-book I’m linking to below), craft some real expository around each solution, and bundle it all up into an e-book and lighter-weight GitHub repo.

There are 11 “quests” in the challenge, requiring sifting through a packet capture (PCAP) and looking for various odds and ends (some are very windy maze passages). The challenge ranges from extracting images and image metadata from FTP sessions to pulling out precise elements in TLS sessions, to dealing with IPv6.

This is far from an expert challenge, and anyone can likely work through it with a little bit of elbow grease.

As it says on the tin, not all data is ‘big’ nor do all data-driven cybersecurity projects require advanced modeling capabilities. Sometimes you just need to dissect some network packet capture (PCAP) data and don’t want to click through a GUI to get the job done. This short book works through the questions in CyberDefenders Lab #68 to show how you can get the Zeek open source network security tool, tshark command-line PCAP analysis Swiss army knife, and R (via RStudio) working together.

FIN

If you find the resource helpful or have other feedback, drop a note on Twitter (@hrbrmstr), in a comment here, or as a GitHub issue.

A Small macOS (Big Sur+) App to Extract Indicators of Compromise

There’s a semi-infrequent-but-frequent-enough-to-be-annoying manual task at $DAYJOB that involves extracting a particular set of strings (identifiable by a fairly benign set of regular expressions) from various interactive text sources (so, not static documents or documents easily scrape-able).

Rather than hack something onto Sublime Text or VS Code I made a small macOS app in SwiftUI that does the extraction when something is pasted.

It occurred to me that this would work for indicators of compromise (IoCs) — because why not add one more to the 5 billion of them on GitHub — and I forked my app, removed all the $WORK bits and added in some code to do just this, and unimaginatively dubbed it extractor. Here’s the main view:

macOS GUI window showing the extractor main view

For now, extractor handles identifying & extracting CIDRs, IPv4s, URLs, hostnames, and email addresses (file issues if you really want hashes, CVE strings or other types) either from:

  • an input URL (it fetches the content and extracts IoCs from the rendered HTML, not the HTML source);
  • items pasted into the textbox (more on some SwiftUI 2 foibles regarding that in a bit); and
  • PDF, HTML, and text files (via Open / ⌘-o)

Here it is extracting IoCs from one of FireEye’s “solarwinds”-related posts:

macOS GUI window showing extracted IoCs from a blog post

If you tick the “Monitor Pasteboard” toggle, the app will monitor the all system-wide additions to the pasteboard, extract the IoCs from them and put them in the textbox. (I think I really need to make this additive to the text in the textbox vs replacing what’s there).

You can save the indicators out to a text file (via Save / ⌘-s) or just copy them from the text box (if you want ndjson or some threat indicator sharing format file an issue).

That SwiftUI 2 Thing I Mentioned

SwiftUI 2 makes app-creation very straightforward, but it also still has many limitations. One of which is how windows/controls handle the “Paste” command. The glue code to make this app really work the way I’d like it to work is just annoying enough to have it on a TODO vs an ISDONE list and I’m hoping SwiftUI 3 comes out with WWDC 2021 (in a scant ~2 months) and provides a less hacky solution.

FIN

You can find the source and notarized binary releases of extractor on GitHub. File issues for questions, feature requests, or problems with the app/code.

Because I used SwiftUI 2, it is very likely possible to have this app work on iOS and iPadOS devices. I can’t see anyone using an iPad for DFIR work, but if you’d like a version of this for iOS/iPadOS, also drop an issue.

Getting a Handle on macOS App Entitlements with R

If you’ve been following me around the internets for a while you’ve likely heard me pontificate about the need to be aware of and reduce — when possible — your personal “cyber” attack surface. One of the ways you can do that is to install as few applications as possible onto your devices and make sure you have a decent handle on those you’ve kept around are doing or capable of doing.

On macOS, one application attribute you can look at is the set of “entitlements” apps have asked for and that you have actioned on (i.e. either granted or denied the entitlement request). If you have Developer Tools or Xcode installed you can use the codesign utility (it may be usable w/o the developer tools, but I never run without them so drop a note in the comments if you can confirm this) to see them:

$ codesign -d --entitlements :- /Applications/RStudio.app
Executable=/Applications/RStudio.app/Contents/MacOS/RStudio
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple Computer//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>

  <!-- Required by R packages which want to access the camera. -->
  <key>com.apple.security.device.camera</key>
  <true/>

  <!-- Required by R packages which want to access the microphone. -->
  <key>com.apple.security.device.audio-input</key>
  <true/>

  <!-- Required by Qt / Chromium. -->
  <key>com.apple.security.cs.disable-library-validation</key>
  <true/>
  <key>com.apple.security.cs.disable-executable-page-protection</key>
  <true/>

  <!-- We use DYLD_INSERT_LIBRARIES to load the libR.dylib dynamically. -->
  <key>com.apple.security.cs.allow-dyld-environment-variables</key>
  <true/>

  <!-- Required to knit to Word -->
  <key>com.apple.security.automation.apple-events</key>
  <true/>

</dict>
</plist>

The output is (ugh) XML, and don’t think that all app developers are as awesome as RStudio ones since those comments are pseudo-optional (i.e. you can put junk in them). I’ll continue to use RStudio throughout this example just for consistency.

Since you likely have better things to do than execute a command line tool multiple times and do significant damage to your eyes with all those pointy tags we can use R to turn the apps on our filesystem into data and examine the entitlements in a much more dignified manner.

First, we’ll write a function to wrap the codesign tool execution (and, I’ve leaked how were going to eventually look at them by putting all the library calls up front):

library(XML)
library(tidyverse)
library(igraph)
library(tidygraph)
library(ggraph)

# rewriting this to also grab the text from the comments is an exercise left to the reader

read_entitlements <- function(app) {

  system2(
    command = "codesign",
    args = c(
      "-d",
      "--entitlements",
      ":-",
      gsub(" ", "\\\\ ", app)
    ),
    stdout = TRUE
  ) -> x

  x <- paste0(x, collapse = "\n")

  if (nchar(x) == 0) return(tibble())

  x <- XML::xmlParse(x, asText=TRUE)
  x <- try(XML::readKeyValueDB(x), silent = TRUE)

  if (inherits(x, "try-error")) return(tibble())

  x <- sapply(x, function(.x) paste0(.x, collapse=";"))

  if (length(x) == 0) return(tibble())

  data.frame(
    app = basename(app),
    entitlement = make.unique(names(x)),
    value = I(x)
  ) -> x

  x <- tibble::as_tibble(x)

  x

}

Now, we can slurp up all the entitlements with just a few lines of code:

my_apps <- list.files("/Applications", pattern = "\\.app$", full.names = TRUE)

my_apps_entitlements <- map_df(my_apps, read_entitlements)

my_apps_entitlements %>%
  filter(grepl("RStudio", app))
## # A tibble: 6 x 3
##   app         entitlement                                              value
##   <chr>       <chr>                                                    <I<chr>>
## 1 RStudio.app com.apple.security.device.camera                         TRUE
## 2 RStudio.app com.apple.security.device.audio-input                    TRUE
## 3 RStudio.app com.apple.security.cs.disable-library-validation         TRUE
## 4 RStudio.app com.apple.security.cs.disable-executable-page-protection TRUE
## 5 RStudio.app com.apple.security.cs.allow-dyld-environment-variables   TRUE
## 6 RStudio.app com.apple.security.automation.apple-events               TRUE

Having these entitlement strings is great, but what do they mean? Unfortunately, Apple, frankly, sucks at developer documentation, and this suckage shines especially bright when it comes to documenting all the possible entitlements. We can retrieve some of them from the online documentation, so let’s do that and re-look at RStudio:

# a handful of fairly ok json URLs that back the online dev docs; they have ok, but scant entitlement definitions
c(
  "https://developer.apple.com/tutorials/data/documentation/bundleresources/entitlements.json",
  "https://developer.apple.com/tutorials/data/documentation/security/app_sandbox.json",
  "https://developer.apple.com/tutorials/data/documentation/security/hardened_runtime.json",
  "https://developer.apple.com/tutorials/data/documentation/bundleresources/entitlements/system_extensions.json"
) -> entitlements_info_urls

extract_entitlements_info <- function(x) {

  apple_ents_pg <- jsonlite::fromJSON(x)

  apple_ents_pg$references %>%
    map_df(~{

      if (!hasName(.x, "role")) return(tibble())
      if (.x$role != "symbol") return(tibble())

      tibble(
        title = .x$title,
        entitlement = .x$name,
        description = .x$abstract$text %||% NA_character_
      )

    })

}

entitlements_info_urls %>%
  map(extract_ents_info) %>%
  bind_rows() %>%
  distinct() -> apple_entitlements_definitions

# look at rstudio again ---------------------------------------------------

my_apps_entitlements %>%
  left_join(apple_entitlements_definitions) %>%
  filter(grepl("RStudio", app)) %>%
  select(title, description)
## Joining, by = "entitlement"
## # A tibble: 6 x 2
##   title                            description
##   <chr>                            <chr>
## 1 Camera Entitlement               A Boolean value that indicates whether the app may capture movies…
## 2 Audio Input Entitlement          A Boolean value that indicates whether the app may record audio u…
## 3 Disable Library Validation Enti… A Boolean value that indicates whether the app may load arbitrary…
## 4 Disable Executable Memory Prote… A Boolean value that indicates whether to disable all code signin…
## 5 Allow DYLD Environment Variable… A Boolean value that indicates whether the app may be affected by…
## 6 Apple Events Entitlement         A Boolean value that indicates whether the app may prompt the use…

It might be interesting to see what the most requested entitlements are:


my_apps_entitlements %>%
  filter(
    grepl("security", entitlement)
  ) %>%
  count(entitlement, sort = TRUE)
## # A tibble: 60 x 2
##    entitlement                                           n
##    <chr>                                             <int>
##  1 com.apple.security.app-sandbox                       51
##  2 com.apple.security.network.client                    44
##  3 com.apple.security.files.user-selected.read-write    35
##  4 com.apple.security.application-groups                29
##  5 com.apple.security.automation.apple-events           26
##  6 com.apple.security.device.audio-input                19
##  7 com.apple.security.device.camera                     17
##  8 com.apple.security.files.bookmarks.app-scope         16
##  9 com.apple.security.network.server                    16
## 10 com.apple.security.cs.disable-library-validation     15
## # … with 50 more rows

Playing in an app sandbox, talking to the internet, and handling files are unsurprising in the top three slots since that’s how most apps get stuff done for you.

There are a few entitlements which increase your attack surface, one of which is apps that use untrusted third-party libraries:

my_apps_entitlements %>%
  filter(
    entitlement == "com.apple.security.cs.disable-library-validation"
  ) %>%
  select(app)
## # A tibble: 15 x 1
##    app
##    <chr>
##  1 Epic Games Launcher.app
##  2 GarageBand.app
##  3 HandBrake.app
##  4 IINA.app
##  5 iStat Menus.app
##  6 krisp.app
##  7 Microsoft Excel.app
##  8 Microsoft PowerPoint.app
##  9 Microsoft Word.app
## 10 Mirror for Chromecast.app
## 11 Overflow.app
## 12 R.app
## 13 RStudio.app
## 14 RSwitch.app
## 15 Wireshark.app

(‘Tis ironic that one of Apple’s own apps is in that list.)

What about apps that listen on the network (i.e. are also servers)?

## # A tibble: 16 x 1
##    app
##    <chr>
##  1 1Blocker.app
##  2 1Password 7.app
##  3 Adblock Plus.app
##  4 Divinity - Original Sin 2.app
##  5 Fantastical.app
##  6 feedly.app
##  7 GarageBand.app
##  8 iMovie.app
##  9 Keynote.app
## 10 Kindle.app
## 11 Microsoft Remote Desktop.app
## 12 Mirror for Chromecast.app
## 13 Slack.app
## 14 Tailscale.app
## 15 Telegram.app
## 16 xScope.app

You should read through the retrieved definitions to see what else you may want to observe to be an informed macOS app user.

The Big Picture

Looking at individual apps is great, but why not look at them all? We can build a large, but searchable network graph hierarchy if we output it as PDf, so let’s do that:

# this is just some brutish force code to build a hierarchical edge list

my_apps_entitlements %>%
  distinct(entitlement) %>%
  pull(entitlement) %>%
  stri_count_fixed(".") %>%
  max() -> max_dots

my_apps_entitlements %>%
  distinct(entitlement, app) %>%
  separate(
    entitlement,
    into = sprintf("level_%02d", 1:(max_dots+1)),
    fill = "right",
    sep = "\\."
  ) %>%
  select(
    starts_with("level"), app
  ) -> wide_hierarchy

bind_rows(

  distinct(wide_hierarchy, level_01) %>%
    rename(to = level_01) %>%
    mutate(from = ".") %>%
    select(from, to) %>%
    mutate(to = sprintf("%s_1", to)),

  map_df(1:nrow(wide_hierarchy), ~{

    wide_hierarchy[.x,] %>%
      unlist(use.names = FALSE) %>%
      na.exclude() -> tmp

    tibble(
      from = tail(lag(tmp), -1),
      to = head(lead(tmp), -1),
      lvl = 1:length(from)
    ) %>%
      mutate(
        from = sprintf("%s_%d", from, lvl),
        to = sprintf("%s_%d", to, lvl+1)
      )

  }) %>%
    distinct()

) -> long_hierarchy

# all that so we can make a pretty graph! ---------------------------------

g <- graph_from_data_frame(long_hierarchy, directed = TRUE)

ggraph(g, 'partition', circular = FALSE) +
  geom_edge_diagonal2(
    width = 0.125, color = "gray70"
  ) +
  geom_node_text(
    aes(
      label = stri_replace_last_regex(name, "_[[:digit:]]+$", "")
    ),
    hjust = 0, size = 3, family = font_gs
  ) +
  coord_flip() -> gg

# saving as PDF b/c it is ginormous, but very searchable

quartz(
  file = "~/output-tmp/.pdf", # put it where you want
  width = 21,
  height = 88,
  type = "pdf",
  family = font_gs
)
print(gg)
dev.off()

The above generates a large (dimension-wise; it’s ~<5MB on disk for me) PDF graph that is barely viewable in thumnail mode:

Here are some screen captures of portions of it. First are all network servers and clients:

Last are seekrit entitlements only for Apple:

FIN

I’ll likely put a few of these functions into {mactheknife} for easier usage.

After going through this exercise I deleted 11 apps, some for their entitlements and others that I just never use anymore. Hopefully this will help you do some early Spring cleaning as well.

Soon May the Vendorman Come

There was an org that didn’t see
The data exfil hacking spree.
A patch went up, our guard was down,
Oh blow, SolarWinds, blow.

Soon may the Vendorman come,
And bring us Yara rules to run.
One day when their huntin’ is done,
They’ll take their scripts and go.

There was no implant here before,
But after was a sly backdoor.
The C2 signals they did soar
And labored low and slow.

As the attack did laterally move
Our foe did get into their groove;
Stealing certs; installing ‘sploits
Wher’er they did go.

Then one day in the by and by,
Some clever folk with a firey-eye,
Spotted something amiss in Orion’s belt
And a delvin’ they did go.

The sunburst cleared and they did see
The origin of their recent misery.
A blog went up; they did proclaim
Many other orgs were laid low.

As far as I’ve heard, the fight’s still on;
The C2s blocked but the attackers aren’t done.
The Vendorman makes his regular call
To help CISO, crew and all.

A Look at PAN-OS Versions with a Bit of R

The incredibly talented folks over at Bishop Fox were quite generous this week, providing a scanner for figuring out PAN-OS GlobalProtect versions. I’ve been using their decoding technique and date-based fingerprint table to keep an eye on patch status (over at $DAYJOB we help customers, organizations, and national cybersecurity centers get ahead of issues as best as we can).

We have at-scale platforms for scanning the internet and aren’t running the panos-scanner repo code, but I since there is Python code for doing this, I thought it might be fun to show R folks how to do the same thing and show folks how to use the {httr} package to build something similar (we won’t hit all the URLs their script assesses, primarily for brevity).

What Are We Doing Again?

Palo Alto makes many things, most of which are built on their custom linux distribution dubbed PAN-OS. One of the things they build is a VPN product that lets users remotely access internal company resources. It’s had quite the number of pretty horrible problems of late.

Folks contracted to assess security defenses (colloquially dubbed “pen-testers” tho no pens are usually involved) and practitioners within an organization who want to gain an independent view of what their internet perimeter looks like often assemble tools to perform
ad-hoc assessments. Sure, there are commercial tools for performing these assessments ($DAYJOB makes some!), but these open source tools make it possible for folks to learn from each other and for makers of products (like PAN-OS) to do a better job securing their creations.

In this case, the creation is a script that lets the caller figure out what version of PAN-OS is running on a given GlobalProtect box.

To follow along at home, you’ll need access to a PAN-OS system, as I’m not providing an IP address of one for you. It’s really not hard to find one (just google a bit or stand up a trial one from the vendor). Throughout the examples I’ll be using {glue} to replace ip and port in various function calls, so let’s get some setup bits out of the way:

library(httr)
library(tidyverse) # for read_fwf() (et al), pluck(), filter(), and %>%

gg <- glue::glue # no need to bring in the entire namespace just for this

Assuming you have a valid ip and port, let’s try making a request against your PAN-OS GlobalProtect (hereafter using “GP” so save keystrokes) system:

httr::HEAD(
  url = gg("https://{ip}:{port}/global-protect/login.esp")
) -> res
## Error in curl::curl_fetch_memory(url, handle = handle) :
##  SSL certificate problem: self signed certificate

We’re using a HEAD request as we really don’t need the contents of the remote file (unless you need to verify it truly is a PAN-OS GP server), just the metadata about it. You can use a traditional GET request if you like, though.

We immediately run into a snag since these boxes tend to use a self-signed SSL/TLS certificate which web clients aren’t thrilled about dealing with unless explicitly configured to. We can circumvent this with some configuration options, but you should not use the following incantations haphazardly. SSL/TLS no longer really means what it used to (thanks, Let’s Encrypt!) but you have no guarantees of what’s being delivered to you is legitimate if you hit a plaintext web site or one with an invalid certificate. Enough with the soapbox, let’s make the request:

httr::HEAD(
  url = gg("https://{ip}:{port}/global-protect/login.esp"),
  config = httr::config(
    ssl_verifyhost =FALSE,
    ssl_verifypeer = FALSE
  )
) -> res

httr::status_code(res)
## [1] 200

In that request, we’ve told the underlying {curl} library calls to not verify the validity of the host or peer certificates associated with the service. Again, don’t do this haphazardly to get around generic SSL/TLS problems when making normal API calls or scraping sites.

Since we only made a HEAD request, we’re just getting back headers, so let’s take a look at them:

str(httr::headers(res), 1)
## List of 18
##  $ date                     : chr "Fri, 10 Jul 2020 15:02:32 GMT"
##  $ content-type             : chr "text/html; charset=UTF-8"
##  $ content-length           : chr "11749"
##  $ connection               : chr "keep-alive"
##  $ etag                     : chr "\"7e0d5e2b6add\""
##  $ pragma                   : chr "no-cache"
##  $ cache-control            : chr "no-store, no-cache, must-revalidate, post-check=0, pre-check=0"
##  $ expires                  : chr "Thu, 19 Nov 1981 08:52:00 GMT"
##  $ x-frame-options          : chr "DENY"
##  $ set-cookie               : chr "PHPSESSID=bde5668131c14b765e3e75f8ed5514a0; path=/; secure; HttpOnly"
##  $ set-cookie               : chr "PHPSESSID=bde5668131c14b765e3e75f8ed5514a0; path=/; secure; HttpOnly"
##  $ set-cookie               : chr "PHPSESSID=bde5668131c14b765e3e75f8ed5514a0; path=/; secure; HttpOnly"
##  $ set-cookie               : chr "PHPSESSID=bde5668131c14b765e3e75f8ed5514a0; path=/; secure; HttpOnly"
##  $ set-cookie               : chr "PHPSESSID=bde5668131c14b765e3e75f8ed5514a0; path=/; samesite=lax; secure; httponly"
##  $ strict-transport-security: chr "max-age=31536000;"
##  $ x-xss-protection         : chr "1; mode=block;"
##  $ x-content-type-options   : chr "nosniff"
##  $ content-security-policy  : chr "default-src 'self'; script-src 'self' 'unsafe-inline'; img-src * data:; style-src 'self' 'unsafe-inline';"
##  - attr(*, "class")= chr [1:2] "insensitive" "list"

As an aside, I’ve always found the use of PHP code in security products quite, er, fascinating.

The value we’re really looking for here is etag (which really looks like ETag in the raw response).

Bishop Fox (and others) figured out that that header value contains a timestamp in the last 8 characters. That timestamp maps to the release date of the particular PAN-OS version. Since Palo Alto maintains multiple, supported versions of PAN-OS and generally releases patches for them all at the same time, the mapping to an exact version is not super precise, but it’s sufficient to get an idea of whether that system is at a current, supported patch level.

The last 8 characters of 7e0d5e2b6add are 5e2b6add, which — as Bishop Fox notes in their repo — is just a hexadecimal encoding of the POSIX timestamp, in this case, 1579903709 or 2020-01-24 22:08:29 GMT (we only care about the date, so really 2020-01-24).

We can compute that with R, but first we need to note that the value is surrounded by " quotes, so we’ll have to deal with that during the processing:

httr::headers(res) %>%
  pluck("etag") %>%
  gsub('"', '', .) %>%
  substr(5, 12) %>%
  as.hexmode() %>%
  as.integer() %>%
  anytime::anytime(tz = "GMT") %>%
  as.Date() -> version_date

version_date
## [1] "2020-01-24"

To get the associated version(s), we need to look the date up in their table, which is in a fixed-width format that we can read via:

read_fwf(
  file = "https://raw.githubusercontent.com/noperator/panos-scanner/master/version-table.txt",
  col_positions = fwf_widths(c(10, 14), c("version", "date")),
  col_types = "cc",
  trim_ws = TRUE
) %>%
  mutate(
    date = lubridate::mdy(date)
  ) -> panos_trans

panos_trans
## # A tibble: 153 x 2
##    version  date
##    <chr>    <date>
##  1 6.0.0    2013-12-23
##  2 6.0.1    2014-02-26
##  3 6.0.2    2014-04-18
##  4 6.0.3    2014-05-29
##  5 6.0.4    2014-07-30
##  6 6.0.5    2014-09-04
##  7 6.0.5-h3 2014-10-07
##  8 6.0.6    2014-10-07
##  9 6.0.7    2014-11-18
## 10 6.0.8    2015-01-13
## # … with 143 more rows

Now, let’s see what version or versions this might be:

filter(panos_trans, date == version_date)
## # A tibble: 2 x 2
##   version date
##   <chr>   <date>
## 1 9.0.6   2020-01-24
## 2 9.1.1   2020-01-24

Putting It All Together

We can make a command line script for this (example) scanner:

#!env Rscript
library(purrr)

gg <- glue::glue

# we also use {httr}, {readr}, {lubridate}, {anytime}, and {jsonlite}

args <- commandArgs(trailingOnly = TRUE)

stopifnot(
  c(
    "Must supply both IP address and port" = length(args) == 2
  )
)

ip <- args[1]
port <-  args[2]

httr::HEAD(
  url = gg("https://{ip}:{port}/global-protect/login.esp"),
  config = httr::config(
    ssl_verifyhost =FALSE,
    ssl_verifypeer = FALSE
  )
) -> res

httr::headers(res) %>%
  pluck("etag") %>%
  gsub('"', '', .) %>%
  substr(5, 12) %>%
  as.hexmode() %>%
  as.integer() %>%
  anytime::anytime(tz = "GMT") %>%
  as.Date() -> version_date

panos_trans <- readr::read_csv("panos-versions.txt", col_types = "cD")

res <- panos_trans[panos_trans[["date"]] == version_date,]

if (nrow(res) == 0) {
  cat(gg('{{"ip":"{ip}","port":"{port}","version"=null,"date"=null}}\n'))
} else {
  res$ip <- ip
  res$port <- port
  jsonlite::stream_out(res[,c("ip", "port", "version", "date")], verbose = FALSE)
}

Save that as panos-scanner.R and make it executable (provided you’re on a non-legacy operating system that doesn’t support such modern capabilities). Save panos_trans as a CSV file in the same directory and try it against another (sanitized IP/port) system:

./panos-scanner.R 10.20.30.40 5678                                                                                                                                                    1
{"ip":"10.20.30.40","port":"5678","version":"9.1.2","date":"2020-03-30"}

FIN

To be complete, the script should test all the URLs the ones in the script from Bishop Fox does and stand up many more guard rails to handle errors associated with unreachable hosts, getting headers from a system that is not a PAN-OS GP host, and ensuring the ETag is a valid date.

You can grab the code [from this repo](https://git.rud.is/hrbrmstr/2020-07-10-panos-rstats.

CRAN Mirror “Security”

In the “Changes on CRAN” section of the latest version of the The R Journal (Vol. 10/2, December 2018) had this short blurb entitled “CRAN mirror security”:

Currently, there are 100 official CRAN mirrors, 68 of which provide both secure downloads via ‘https’ and use secure mirroring from the CRAN master (via rsync through ssh tunnels). Since the R 3.4.0 release, chooseCRANmirror() offers these mirrors in preference to the others which are not fully secured (yet).

I would have linked to the R Journal section quoted above but I can’t because I’m blocked from accessing all resources at the IP address serving cran.r-project.org from my business-class internet connection likely due to me having a personal CRAN mirror (that was following the rules, which I also cannot link to since I can’t get to the site).

That word — “security” — is one of the most misunderstood and misused terms in modern times in many contexts. The context for the use here is cybersecurity and since CRAN (and others in the R community) seem to equate transport-layer uber-obfuscation with actual security/safety I thought it would be useful for R users in general to get a more complete picture of these so-called “secure” hosts. I also did this since I had to figure out another way to continue to have a CRAN mirror and needed to validate which nodes both supported + allowed mirroring and were at least somewhat trustworthy.

Unless there is something truly egregious in a given section I’m just going to present data with some commentary (I’m unamused abt being blocked so some commentary has an unusually sharp edge) and refrain from stating “X is 👍|👎” since the goal is really to help you make the best decision of which mirror to use on your own.

The full Rproj supporting the snippets in this post (and including the data gathered by the post) can be found in my new R blog projects.

We’re going to need a few supporting packages so let’s get those out of the way:

library(xml2)
library(httr)
library(curl)
library(stringi)
library(urltools)
library(ipinfo) # install.packages("ipinfo", repos = "https://cinc.rud.is/")
library(openssl)
library(furrr)
library(vershist) # install.packages("vershist", repos = "https://cinc.rud.is/")
library(ggalt)
library(ggbeeswarm)
library(hrbrthemes)
library(tidyverse)

What Is “Secure”?

As noted, CRAN folks seem to think encryption == security since the criteria for making that claim in the R Journal was transport-layer encryption for rsync (via ssh) mirroring from CRAN to a downstream mirror and a downstream mirror providing an https transport for shuffling package binaries and sources from said mirror to your local system(s). I find that equally as adorable as I do the rhetoric from the Let’s Encrypt cabal as this https gets you:

  • in theory protection from person-in-the-middle attacks that could otherwise fiddle with the package bits in transport
  • protection from your organization or ISP knowing what specific package you were grabbing; note that unless you’ve got a setup where your DNS requests are also encrypted the entity that controls your transport layer does indeed know exactly where you’re going.

and…that’s about it.

The soon-to-be-gone-and-formerly-green-in-most-browsers lock icon alone tells you nothing about the configuration of any site you’re connecting to and using rsync over ssh provides no assurance as to what else is on the CRAN mirror server(s), what else is using the mirror server(s), how many admins/users have shell access to those system(s) nor anything else about the cyber hygiene of those systems.

So, we’re going to look at (not necessarily in this order & non-exhaustively since this isn’t a penetration test and only lightweight introspection has been performed):

  • how many servers are involved in a given mirror URL
  • SSL certificate information including issuer, strength, and just how many other domains can use the cert
  • the actual server SSL transport configuration to see just how many CRAN mirrors have HIGH or CRITICAL SSL configuration issues
  • use (or lack thereof) HTTP “security” headers (I mean, the server is supposed to be “secure”, right?)
  • how much other “junk” is running on a given CRAN mirror (the more running services the greater the attack surface)

We’ll use R for most of this, too (I’m likely never going to rewrite longstanding SSL testers in/for R).

Let’s dig in.

Acquiring Most of the Metadata

It can take a little while to run some of the data gathering steps so the project repo includes the already-gathered data. But, we’ll show the work on the first bit of reconnaissance which involves:

  • Slurping the SSL certificate from the first server in each CRAN mirror entry (again, I can’t link to the mirror page because I literally can’t see CRAN or the main R site anymore)
  • Performing an HTTP HEAD request (to minimize server bandwidth & CPU usage) of the full CRAN mirror URL (we have to since load balancers or proxies could re-route us to a completely different server otherwise)
  • Getting an IP address for each CRAN mirror
  • Getting metadata about that IP address

This all done below:

if (!file.exists(here::here("data/mir-dat.rds"))) {
  mdoc <- xml2::read_xml(here::here("data/mirrors.html"), as_html = TRUE)

  xml_find_all(mdoc, ".//td/a[contains(@href, 'https')]") %>%
    xml_attr("href") %>%
    unique() -> ssl_mirrors

  plan(multiprocess)

  # safety first
  dl_cert <- possibly(openssl::download_ssl_cert, NULL)
  HEAD_ <- possibly(httr::HEAD, NULL)
  dig <- possibly(curl::nslookup, NULL)
  query_ip_ <- possibly(ipinfo::query_ip, NULL)

  ssl_mirrors %>%
    future_map(~{
      host <- domain(.x)
      ip <- dig(host, TRUE)
      ip_info <- if (length(ip)) query_ip_(ip) else NULL
      list(
        host = host,
        cert = dl_cert(host),
        head = HEAD_(.x),
        ip = ip,
        ip_info = ip_info
      )
    }) -> mir_dat

  saveRDS(mir_dat, here::here("data/mir-dat.rds"))
} else {
  mir_dat <- readRDS(here::here("data/mir-dat.rds"))
}

# take a look

str(mir_dat[1], 3)
## List of 1
##  $ :List of 5
##   ..$ host   : chr "cloud.r-project.org"
##   ..$ cert   :List of 4
##   .. ..$ :List of 8
##   .. ..$ :List of 8
##   .. ..$ :List of 8
##   .. ..$ :List of 8
##   ..$ head   :List of 10
##   .. ..$ url        : chr "https://cloud.r-project.org/"
##   .. ..$ status_code: int 200
##   .. ..$ headers    :List of 13
##   .. .. ..- attr(*, "class")= chr [1:2] "insensitive" "list"
##   .. ..$ all_headers:List of 1
##   .. ..$ cookies    :'data.frame':   0 obs. of  7 variables:
##   .. ..$ content    : raw(0)
##   .. ..$ date       : POSIXct[1:1], format: "2018-11-29 09:41:27"
##   .. ..$ times      : Named num [1:6] 0 0.0507 0.0512 0.0666 0.0796 ...
##   .. .. ..- attr(*, "names")= chr [1:6] "redirect" "namelookup" "connect" "pretransfer" ...
##   .. ..$ request    :List of 7
##   .. .. ..- attr(*, "class")= chr "request"
##   .. ..$ handle     :Class 'curl_handle' <externalptr>
##   .. ..- attr(*, "class")= chr "response"
##   ..$ ip     : chr "52.85.89.62"
##   ..$ ip_info:List of 8
##   .. ..$ ip      : chr "52.85.89.62"
##   .. ..$ hostname: chr "server-52-85-89-62.jfk6.r.cloudfront.net"
##   .. ..$ city    : chr "Seattle"
##   .. ..$ region  : chr "Washington"
##   .. ..$ country : chr "US"
##   .. ..$ loc     : chr "47.6348,-122.3450"
##   .. ..$ postal  : chr "98109"
##   .. ..$ org     : chr "AS16509 Amazon.com, Inc."

Note that two sites failed to respond so they were excluded from all analyses.

A Gratuitous Map of “Secure” CRAN Servers

Since ipinfo.io‘s API returns lat/lng geolocation information why not start with a map (since that’s going to be the kindest section of this post):

maps::map("world", ".", exact = FALSE, plot = FALSE,  fill = TRUE) %>%
  fortify() %>%
  filter(region != "Antarctica") -> world

map_chr(mir_dat, ~.x$ip_info$loc) %>%
  stri_split_fixed(pattern = ",", n = 2, simplify = TRUE) %>%
  as.data.frame(stringsAsFactors = FALSE) %>%
  as_tibble() %>%
  mutate_all(list(as.numeric)) -> wheres_cran

ggplot() +
  ggalt::geom_cartogram(
    data = world, map = world, aes(long, lat, map_id=region),
    color = ft_cols$gray, size = 0.125
  ) +
  geom_point(
    data = wheres_cran, aes(V2, V1), size = 2,
    color = ft_cols$slate, fill = alpha(ft_cols$yellow, 3/4), shape = 21
  ) +
  ggalt::coord_proj("+proj=wintri") +
  labs(
    x = NULL, y = NULL,
    title = "Geolocation of HTTPS-'enabled' CRAN Mirrors"
  ) +
  theme_ft_rc(grid="") +
  theme(axis.text = element_blank())

Shakesperian Security

What’s in a [Subject Alternative] name? That which we call a site secure. By using dozens of other names would smell as not really secure at all? —Hackmeyo & Pwndmeyet (II, ii, 1-2)

The average internet user likely has no idea that one SSL certificate can front a gazillion sites. I’m not just talking a wildcard cert (e.g. using *.rud.is for all rud.is subdomains which I try not to do for many reasons), I’m talking dozens of subject alternative names. Let’s examine some data since an example is better than blathering:

# extract some of the gathered metadata into a data frame
map_df(mir_dat, ~{
  tibble(
    host = .x$host,
    s_issuer = .x$cert[[1]]$issuer %||% NA_character_,
    i_issuer = .x$cert[[2]]$issuer %||% NA_character_,
    algo = .x$cert[[1]]$algorithm %||% NA_character_,
    names = .x$cert[[1]]$alt_names %||% NA_character_,
    nm_ct = length(.x$cert[[1]]$alt_names),
    key_size = .x$cert[[1]]$pubkey$size %||% NA_integer_
  )
}) -> certs

certs <- filter(certs, complete.cases(certs))

count(certs, host, sort=TRUE) %>%
  ggplot() +
  geom_quasirandom(
    aes("", n), size = 2,
    color = ft_cols$slate, fill = alpha(ft_cols$yellow, 3/4), shape = 21
  ) +
  scale_y_comma() +
  labs(
    x = NULL, y = "# Servers",
    title = "Distribution of the number of alt-names in CRAN mirror certificates"
  ) +
  theme_ft_rc(grid="Y")

Most only front a couple but there are some with a crazy amount of domains. We can look at a slice of cran.cnr.berkeley.edu:

filter(certs, host == "cran.cnr.berkeley.edu") %>%
  select(names) %>%
  head(20)
names
nature.berkeley.edu
ag-labor.cnr.berkeley.edu
agro-laboral.cnr.berkeley.edu
agroecology.berkeley.edu
anthoff.erg.berkeley.edu
are-dev.cnr.berkeley.edu
are-prod.cnr.berkeley.edu
are-qa.cnr.berkeley.edu
are.berkeley.edu
arebeta.berkeley.edu
areweb.berkeley.edu
atkins-dev.cnr.berkeley.edu
atkins-prod.cnr.berkeley.edu
atkins-qa.cnr.berkeley.edu
atkins.berkeley.edu
bakerlab-dev.cnr.berkeley.edu
bakerlab-prod.cnr.berkeley.edu
bakerlab-qa.cnr.berkeley.edu
bamg.cnr.berkeley.edu
beahrselp-dev.cnr.berkeley.edu

The project repo has some more examples and you can examine as many as you like.

For some CRAN mirrors the certificate is used all over the place at the hosting organization. That alone isn’t bad, but organizations are generally terrible at protecting the secrets associated with certificate generation (just look at how many Google/Apple app store apps are found monthly to be using absconded-with enterprise certs) and since each server with these uber-certs has copies of public & private bits users had better hope that mal-intentioned ne’er-do-wells do not get copies of them (making it easier to impersonate any one of those, especially if an attacker controls DNS).

This Berkeley uber-cert is also kinda cute since it mixes alt-names for dev, prod & qa systems across may different apps/projects (dev systems are notoriously maintained improperly in virtually every organization).

There are legitimate reasons and circumstances for wildcard certs and taking advantage of SANs. You can examine what other CRAN mirrors do and judge for yourself which ones are Doing It Kinda OK.

Size (and Algorithm) Matters

In some crazy twist of pleasant surprises most of the mirrors seem to do OK when it comes to the algorithm and key size used for the certificate(s):

distinct(certs, host, algo, key_size) %>%
  count(algo, key_size, sort=TRUE)
algo key_size n
sha256WithRSAEncryption 2048 59
sha256WithRSAEncryption 4096 13
ecdsa-with-SHA256 256 2
sha256WithRSAEncryption 256 1
sha256WithRSAEncryption 384 1
sha512WithRSAEncryption 2048 1
sha512WithRSAEncryption 4096 1

You can go to the mirror list and hit up SSL Labs Interactive Server Test (which has links to many ‘splainers) or use the ssllabs🔗 R package to get the grade of each site. I dig into the state of config and transport issues below but will suggest that you stick with sites with ecdsa certs or sha256 and higher numbers if you want a general, quick bit of guidance.

Where Do They Get All These Wonderful Certs?

Certs come from somewhere. You can self-generate play ones, setup your own internal/legit certificate authority and augment trust chains, or go to a bona-fide certificate authority to get a certificate.

Your browsers and operating systems have a built-in set of certificate authorities they trust and you can use ssllabs::get_root_certs()🔗 to see an up-to-date list of ones for Mozilla, Apple, Android, Java & Windows. In the age of Let’s Encrypt, certificates have almost no monetary value and virtually no integrity value so where they come from isn’t as important as it used to be, but it’s kinda fun to poke at it anyway:

distinct(certs, host, i_issuer) %>%
  count(i_issuer, sort = TRUE) %>%
  head(28)
i_issuer n
CN=DST Root CA X3,O=Digital Signature Trust Co. 20
CN=COMODO RSA Certification Authority,O=COMODO CA Limited,L=Salford,ST=Greater Manchester,C=GB 7
CN=DigiCert Assured ID Root CA,OU=www.digicert.com,O=DigiCert Inc,C=US 7
CN=DigiCert Global Root CA,OU=www.digicert.com,O=DigiCert Inc,C=US 6
CN=DigiCert High Assurance EV Root CA,OU=www.digicert.com,O=DigiCert Inc,C=US 6
CN=QuoVadis Root CA 2 G3,O=QuoVadis Limited,C=BM 5
CN=USERTrust RSA Certification Authority,O=The USERTRUST Network,L=Jersey City,ST=New Jersey,C=US 5
CN=GlobalSign Root CA,OU=Root CA,O=GlobalSign nv-sa,C=BE 4
CN=Trusted Root CA SHA256 G2,O=GlobalSign nv-sa,OU=Trusted Root,C=BE 3
CN=COMODO ECC Certification Authority,O=COMODO CA Limited,L=Salford,ST=Greater Manchester,C=GB 2
CN=DFN-Verein PCA Global – G01,OU=DFN-PKI,O=DFN-Verein,C=DE 2
OU=Security Communication RootCA2,O=SECOM Trust Systems CO.\,LTD.,C=JP 2
CN=AddTrust External CA Root,OU=AddTrust External TTP Network,O=AddTrust AB,C=SE 1
CN=Amazon Root CA 1,O=Amazon,C=US 1
CN=Baltimore CyberTrust Root,OU=CyberTrust,O=Baltimore,C=IE 1
CN=Certum Trusted Network CA,OU=Certum Certification Authority,O=Unizeto Technologies S.A.,C=PL 1
CN=DFN-Verein Certification Authority 2,OU=DFN-PKI,O=Verein zur Foerderung eines Deutschen Forschungsnetzes e. V.,C=DE 1
CN=Go Daddy Root Certificate Authority – G2,O=GoDaddy.com\, Inc.,L=Scottsdale,ST=Arizona,C=US 1
CN=InCommon RSA Server CA,OU=InCommon,O=Internet2,L=Ann Arbor,ST=MI,C=US 1
CN=QuoVadis Root CA 2,O=QuoVadis Limited,C=BM 1
CN=QuoVadis Root Certification Authority,OU=Root Certification Authority,O=QuoVadis Limited,C=BM 1

That first one is Let’s Encrypt, which is not unexpected since they’re free and super easy to setup/maintain (especially for phishing campaigns).

A “fun” exercise might be to Google/DDG around for historical compromises tied to these CAs (look in the subject ones too if you’re playing with the data at home) and see what, eh, issues they’ve had.

You might want to keep more of an eye on this whole “boring” CA bit, too, since some trust stores are noodling on the idea of trusting surveillance firms and you never know what Microsoft or Google is going to do to placate authoritarian regimes and allow into their trust stores.

At this point in the exercise you’ve got

  • how many domains a certificate fronts
  • certificate strength
  • certificate birthplace

to use when formulating your own decision on what CRAN mirror to use.

But, as noted, certificate breeding is not enough. Let’s dive into the next areas.

It’s In The Way That You Use It

You can’t just look at a cert to evaluate site security. Sure, you can spend 4 days and use the aforementioned ssllabs package to get the rating for each cert (well, if they’ve been cached then an API call won’t be an assessment so you can prime the cache with 4 other ppl in one day and then everyone else can use the cached values and not burn the rate limit) or go one-by-one in the SSL Labs test site, but we can also use a tool like testssl.sh🔗 to gather technical data via interactive protocol examination.

I’m being a bit harsh in this post, so fair’s fair and here are the plaintext results from my own run of testssl.sh for rud.is along with ones from Qualys:

As you can see in the detail pages, I am having an issue with the provider of my .is domain (severe limitation on DNS record counts and types) so I fail CAA checks because I literally can’t add an entry for it nor can I use a different nameserver. Feel encouraged to pick nits about that tho as that should provide sufficient impetus to take two weeks of IRL time and some USD to actually get it transferred (yay. international. domain. providers.)

The project repo has all the results from a weekend run on the CRAN mirrors. No special options were chosen for the runs.

list.files(here::here("data/ssl"), "json$", full.names = TRUE) %>%
  map_df(jsonlite::fromJSON) %>%
  as_tibble() -> ssl_tests

# filter only fields we want to show and get them in order
sev <- c("OK", "LOW", "MEDIUM", "HIGH", "WARN", "CRITICAL")

group_by(ip) %>%
  count(severity) %>%
  ungroup() %>%
  complete(ip = unique(ip), severity = sev) %>%
  mutate(severity = factor(severity, levels = sev)) %>% # order left->right by severity
  arrange(ip) %>%
  mutate(ip = factor(ip, levels = rev(unique(ip)))) %>% # order alpha by mirror name so it's easier to ref
  ggplot(aes(severity, ip, fill=n)) +
  geom_tile(color = "#b2b2b2", size = 0.125) +
  scale_x_discrete(name = NULL, expand = c(0,0.1), position = "top") +
  scale_y_discrete(name = NULL, expand = c(0,0)) +
  viridis::scale_fill_viridis(
    name = "# Tests", option = "cividis", na.value = ft_cols$gray
  ) +
  labs(
    title = "CRAN Mirror SSL Test Summary Findings by Severity"
  ) +
  theme_ft_rc(grid="") +
  theme(axis.text.y = element_text(size = 8, family = "mono")) -> gg

# We're going to move the title vs have too wide of a plot

gb <- ggplot2::ggplotGrob(gg)
gb$layout$l[gb$layout$name %in% "title"] <- 2

grid::grid.newpage()
grid::grid.draw(gb)

Thankfully most SSL checks come back OK. Unfortunately, many do not:

filter(ssl_tests,severity == "HIGH") %>%
  count(id, sort = TRUE)
id n
BREACH 42
cipherlist_3DES_IDEA 37
cipher_order 34
RC4 16
cipher_negotiated 10
LOGJAM-common_primes 9
POODLE_SSL 6
SSLv3 6
cert_expiration_status 1
cert_notAfter 1
fallback_SCSV 1
LOGJAM 1
secure_client_renego 1
filter(ssl_tests,severity == "CRITICAL") %>%
  count(id, sort = TRUE)
id n
cipherlist_LOW 16
TLS1_1 5
CCS 2
cert_chain_of_trust 1
cipherlist_aNULL 1
cipherlist_EXPORT 1
DROWN 1
FREAK 1
ROBOT 1
SSLv2 1

Some CRAN mirror site admins aren’t keeping up with secure SSL configurations. If you’re not familiar with some of the acronyms here are a few (fairly layman-friendly) links:

You’d be hard-pressed to have me say that the presence of these is the end of the world (I mean, you’re trusting random servers to provide packages for you which may run in secure enclaves on production code, so how important can this really be?) but I also wouldn’t attach the word “secure” to any CRAN mirror with HIGH or CRITICAL SSL configuration weaknesses.

Getting Ahead[er] Of Myself

We did the httr::HEAD() request primarily to capture HTTP headers. And, we definitely got some!

map_df(mir_dat, ~{

  if (length(.x$head$headers) == 0) return(NULL)

  host <- .x$host

  flatten_df(.x$head$headers) %>%
    gather(name, value) %>%
    mutate(host = host)

}) -> hdrs

count(hdrs, name, sort=TRUE) %>%
  head(nrow(.))
name n
content-type 79
date 79
server 79
last-modified 72
content-length 67
accept-ranges 65
etag 65
content-encoding 38
connection 28
vary 28
strict-transport-security 13
x-frame-options 8
x-content-type-options 7
cache-control 4
expires 3
x-xss-protection 3
cf-ray 2
expect-ct 2
set-cookie 2
via 2
ms-author-via 1
pragma 1
referrer-policy 1
upgrade 1
x-amz-cf-id 1
x-cache 1
x-permitted-cross-domain 1
x-powered-by 1
x-robots-tag 1
x-tuna-mirror-id 1
x-ua-compatible 1

There are a handful of “security” headers that kinda matter so we’ll see how many “secure” CRAN mirrors use “security” headers:

c(
  "content-security-policy", "x-frame-options", "x-xss-protection",
  "x-content-type-options", "strict-transport-security", "referrer-policy"
) -> secure_headers

count(hdrs, name, sort=TRUE) %>%
  filter(name %in% secure_headers)
name n
strict-transport-security 13
x-frame-options 8
x-content-type-options 7
x-xss-protection 3
referrer-policy 1

I’m honestly shocked any were in use but only a handful or two are using even one “security” header. cran.csiro.au uses all five of the above so good on ya Commonwealth Scientific and Industrial Research Organisation!

I keep putting the word “security” in quotes as R does nothing with these headers when you do an install.packages(). As a whole they’re important but mostly when it comes to your safety when browsing those CRAN mirrors.

I would have liked to have seen at least one with some Content-Security-Policy header, but a girl can at least dream.

Version Aversion

There’s another HTTP response header we can look at, the Server one which is generally there to help attackers figure out whether they should target you further for HTTP server and application attacks. No, I mean it! Back in the day when geeks rules the internets — and it wasn’t just a platform for cat pictures and pwnd IP cameras — things like the Server header were cool because it might help us create server-specific interactions and build cool stuff. Yes, modern day REST APIs are likely better in the long run but the naiveté of the silver age of the internet was definitely something special (and also led to the chaos we have now). But, I digress.

In theory, no HTTP server in it’s rightly configured digital mind would tell you what it’s running down to the version level, but most do. (Again, feel free to pick nits that I let the world know I run nginx…or do I). Assuming the CRAN mirrors haven’t been configured to deceive attackers and report what folks told them to report we can survey what they run behind the browser window:

filter(hdrs, name == "server") %>%
  separate(
    value, c("kind", "version"), sep="/", fill="right", extra="merge"
  ) -> svr

count(svr, kind, sort=TRUE)
kind n
Apache 57
nginx 15
cloudflare 2
CSIRO 1
Hiawatha v10.8.4 1
High Performance 8bit Web Server 1
none 1
openresty 1

I really hope Cloudflare is donating bandwidth vs charging these mirror sites. They’ve likely benefitted greatly from the diverse FOSS projects many of these sites serve. (I hadn’t said anything bad about Cloudflare yet so I had to get one in before the end).

Lots run Apache (makes sense since CRAN-proper does too, not that I can validate that from home since I’m IP blocked…bitter much, hrbrmstr?) Many run nginx. CSIRO likely names their server that on purpose and hasn’t actually written their own web server. Hiawatha is, indeed, a valid web server. While there are also “high performance 8bit web servers” out there I’m willing to bet that’s a joke header value along with “none”. Finally, “openresty” is also a valid web server (it’s nginx++).

We’ll pick on Apache and nginx and see how current patch levels are. Not all return a version number but a good chunk do:

apache_httpd_version_history() %>%
  arrange(rls_date) %>%
  mutate(
    vers = factor(as.character(vers), levels = as.character(vers))
  ) -> apa_all

filter(svr, kind == "Apache") %>%
  filter(!is.na(version)) %>%
  mutate(version = stri_replace_all_regex(version, " .*$", "")) %>%
  count(version) %>%
  separate(version, c("maj", "min", "pat"), sep="\\.", convert = TRUE, fill = "right") %>%
  mutate(pat = ifelse(is.na(pat), 1, pat)) %>%
  mutate(v = sprintf("%s.%s.%s", maj, min, pat)) %>%
  mutate(v = factor(v, levels = apa_all$vers)) %>%
  arrange(v) -> apa_vers

filter(apa_all, vers %in% apa_vers$v) %>%
  arrange(rls_date) %>%
  group_by(rls_year) %>%
  slice(1) %>%
  ungroup() %>%
  arrange(rls_date) -> apa_yrs

ggplot() +
  geom_blank(
    data = apa_vers, aes(v, n)
  ) +
  geom_segment(
    data = apa_yrs, aes(vers, 0, xend=vers, yend=Inf),
    linetype = "dotted", size = 0.25, color = "white"
  ) +
  geom_segment(
    data = apa_vers, aes(v, n, xend=v, yend=0),
    color = ft_cols$gray, size = 8
  ) +
  geom_label(
    data = apa_yrs, aes(vers, Inf, label = rls_year),
    family = font_rc, color = "white", fill = "#262a31", size = 4,
    vjust = 1, hjust = 0, nudge_x = 0.01, label.size = 0
  ) +
  scale_y_comma(limits = c(0, 15)) +
  labs(
    x = "Apache Version #", y = "# Servers",
    title = "CRAN Mirrors Apache Version History"
  ) +
  theme_ft_rc(grid="Y") +
  theme(axis.text.x = element_text(family = "mono", size = 8, color = "white"))

O_O

I’ll let you decide if a six-year-old version of Apache indicates how well a mirror site is run or not. Sure, mitigations could be in place but I see no statement of efficacy on any site so we’ll go with #lazyadmin.

But, it’s gotta be better with nginx, right? It’s all cool & modern!

nginx_version_history() %>%
  arrange(rls_date) %>%
  mutate(
    vers = factor(as.character(vers), levels = as.character(vers))
  ) -> ngx_all

filter(svr, kind == "nginx") %>%
  filter(!is.na(version)) %>%
  mutate(version = stri_replace_all_regex(version, " .*$", "")) %>%
  count(version) %>%
  separate(version, c("maj", "min", "pat"), sep="\\.", convert = TRUE, fill = "right") %>%
  mutate(v = sprintf("%s.%s.%s", maj, min, pat)) %>%
  mutate(v = factor(v, levels = ngx_all$vers)) %>%
  arrange(v) -> ngx_vers

filter(ngx_all, vers %in% ngx_vers$v) %>%
  arrange(rls_date) %>%
  group_by(rls_year) %>%
  slice(1) %>%
  ungroup() %>%
  arrange(rls_date) -> ngx_yrs

ggplot() +
  geom_blank(
    data = ngx_vers, aes(v, n)
  ) +
  geom_segment(
    data = ngx_yrs, aes(vers, 0, xend=vers, yend=Inf),
    linetype = "dotted", size = 0.25, color = "white"
  ) +
  geom_segment(
    data = ngx_vers, aes(v, n, xend=v, yend=0),
    color = ft_cols$gray, size = 8
  ) +
  geom_label(
    data = ngx_yrs, aes(vers, Inf, label = rls_year),
    family = font_rc, color = "white", fill = "#262a31", size = 4,
    vjust = 1, hjust = 0, nudge_x = 0.01, label.size = 0
  ) +
  scale_y_comma(limits = c(0, 15)) +
  labs(
    x = "nginx Version #", y = "# Servers",
    title = "CRAN Mirrors nginx Version History"
  ) +
  theme_ft_rc(grid="Y") +
  theme(axis.text.x = element_text(family = "mono", color = "white"))

🤨

I will at close out this penultimate section with a “thank you!” to the admins at Georg-August-Universität Göttingen and Yamagata University for keeping up with web server patches.

You Made It This Far

If I had known you’d read to the nigh bitter end I would have made cookies. You’ll have to just accept the ones the blog gives your browser (those ones taste taste pretty bland tho).

The last lightweight element we’ll look at is “what else do these ‘secure’ CRAN mirrors run”?

To do this, we’ll turn to Rapid7 OpenData and look at what else is running on the IP addresses used by these CRAN mirrors. We already know some certs are promiscuous, so what about the servers themselves?

cran_mirror_other_things <- readRDS(here::here("data/cran-mirror-other-things.rds"))

# "top" 20
distinct(cran_mirror_other_things, ip, port) %>%
  count(ip, sort = TRUE) %>%
  head(20)
ip n
104.25.94.23 8
143.107.10.17 7
104.27.133.206 5
137.208.57.37 5
192.75.96.254 5
208.81.1.244 5
119.40.117.175 4
130.225.254.116 4
133.24.248.17 4
14.49.99.238 4
148.205.148.16 4
190.64.49.124 4
194.214.26.146 4
200.236.31.1 4
201.159.221.67 4
202.90.159.172 4
217.31.202.63 4
222.66.109.32 4
45.63.11.93 4
62.44.96.11 4

Four isn’t bad since we kinda expect at least 80, 443 and 21 (FTP) to be running. We’ll take those away and look at the distribution:

distinct(cran_mirror_other_things, ip, port) %>%
  filter(!(port %in% c(21, 80, 443))) %>%
  count(ip) %>%
  count(n) %>%
  mutate(n = factor(n)) %>%
  ggplot() +
  geom_segment(
    aes(n, nn, xend = n, yend = 0), size = 10, color = ft_cols$gray
  ) +
  scale_y_comma() +
  labs(
    x = "Total number of running services", y = "# hosts",
    title = "How many other services do CRAN mirrors run?",
    subtitle = "NOTE: Not counting 80/443/21"
  ) +
  theme_ft_rc(grid="Y")

So, what are these other ports?

distinct(cran_mirror_other_things, ip, port) %>%
  count(port, sort=TRUE)
port n
80 75
443 75
21 29
22 18
8080 6
25 5
53 2
2082 2
2086 2
8000 2
8008 2
8443 2
111 1
465 1
587 1
993 1
995 1
2083 1
2087 1

22 is SSH, 53 is DNS, 8000/8008/8080/8553 are web high ports usually associated with admin or API endpoints and generally a bad sign when exposed externally (especially on a “secure” mirror server). 25/465/587/993/995 all deal with mail sending and reading (not exactly a great service to have on a “secure” mirror server). I didn’t poke too hard but 208[2367] tend to be cPanel admin ports and those being internet-accessible is also not great.

Port 111 is sunrpc and is a really bad thing to expose to the internet or to run at all. But, the server is a “secure” CRAN mirror, so perhaps everything is fine.

FIN

While I hope this posts informs, I’ve worked in cybersecurity for ages and — as a result — don’t really expect anything to change. Tomorrow, I’ll still be blocked from the main CRAN & r-project.org site despite having better “security” than the vast majority of these “secure” CRAN mirrors (and was following the rules). Also CRAN mirror settings tend to be fairly invisible since most modern R users use the RStudio default (which is really not a bad choice from any “security” analysis angle), choose the first item in the mirror-chooser (Russian roulette!), or live with the setting in the site-wide Rprofile anyway (org-wide risk acceptance/”blame the admin”).

Since I only stated it way back up top (WordPress says this is ~3,900 words but much of that is [I think] code) you can get the full R project for this and examine the data yourself. There is a bit more data and code in the project since I also looked up the IP addresses in Rapid7’s FDNS OpenData study set to really see how many domains point to a particular CRAN mirror but really didn’t want to drag the post on any further.

Now, where did I put those Python 3 & Julia Jupyter notebooks…
