Waffle House announced it was closing hundreds of stores this week due to SARS-Cov-2 (a.k.a COVID-19). This move garnered quite a bit of media attention since former FEMA Administrator Craig Fugate used the restaurant chain as both an indicator of the immediate and overall severity of a natural disaster. [He’s not the only one](https://www.ehstoday.com/emergency-management/article/21906815/what-do-waffles-have-to-do-with-risk-management. The original concept was pretty straightforward:

For example, if a Waffle House store is open and offering a full menu, the index is green. If it is open but serving from a limited menu, it’s yellow. When the location has been forced to close, the index is red. Because Waffle House is well prepared for disasters, Kouvelis said, it’s rare for the index to hit red. For example, the Joplin, Mo., Waffle House survived the tornado and remained open.

“They know immediately which stores are going to be affected and they call their employees to know who can show up and who cannot,” he said. “They have temporary warehouses where they can store food and most importantly, they know they can operate without a full menu. This is a great example of a company that has learned from the past and developed an excellent emergency plan.”

SARS-Cov-2 is not a tropical storm, so conditions are a bit different and a tad more complex when it comes to basing severity of this particular disaster (mostly caused by inept politicians across the globe), which gave me an idea for how to make the Waffle House Index a proper index, i.e. a _”statistical measure of change in a representative group of individual data points.”_¹.

In the case of an outbreak, rather than a simple green/yellow/red condition state, using the ratio of closed to open Waffle House locations as a numeric index — [0-1] — seems to make more sense since it may better help indicate:

• when shelter-in-place became mandatory where a given restaurant is located
• the severity of SARS-Cov-2-caused symptoms for a given location
• disruptions in the supply chain for a given location due to SARS-Cov-2

I kinda desperately needed a covidistraction so I set out to see how hard it would be to build such an index metric.

Waffle House lets you find locations via a standard map/search interface. They provide lots of data via that map which can be used to figure out which stores are open and which are closed. There’s a nascent R package which contains all the recipes necessary for the data gathering. However, you don’t need to use it, since it powers wafflehouseindex.us which is collecting the data when the store closings info changes and provides a snapshot of the latest data daily (direct CSV link).

The historical data will make it to a git repo at some point in the near future.

The current index value is 21.2, which increased quickly after the first value of 18.1 (that event was the catalyst for getting the site up and package done) and the closed locations are on the map at the beginning of the post. I went with three qualitative levels on the gauge mostly to keep things simple.

There will absolutely be more location closings and it will be interesting (and, ultimately, very depressing and likely grave) to see how high the index goes and how long it stays above zero.

FIN

The metric is — for the time being — computed across all stores. As noted earlier, this could be broken down into regional index scores to intuit the aforementioned three indicators on a more local level. The historical data (apart from the first closings announcement) is being saved so it will be possible to go back and compute regional indexes when I’ve got more time.

I shall reiterate that you should grab the data from http://wafflehouseindex.us/data/latest.csv vs use the R package since there’s no point in dup’ing the gathering and the historical data will be up and maintained soon.

Stay safe, folks.

Über Tuesday has come and almost gone (some state results will take a while to coalesce) and I’m relieved to say that {catchpole} did indeed work, with the example code from before producing this on first run:

If we tweak the buffer space around the squares, I think the cartogram looks better:

but, you should likely use a different palette (see this Twitter thread for examples).

I noted in the previous post that borders might be possible. While I haven’t solved that use-case for individual states, I did manage to come up with a method for making a light version of the cartogram usable:

library(sf)
library(hrbrthemes)
library(catchpole)
library(tidyverse)

delegates <- read_delegates()

candidates_expanded <- expand_candidates()

gsf <- left_join(delegates_map(), candidates_expanded, by = c("state", "idx"))

m <- delegates_map()

# split off each "area" on the map so we can make a border+background
list(
  setdiff(state.abb, c("HI", "AK")),
  "AK", "HI", "DC", "VI", "PR", "MP", "GU", "DA", "AS"
) %>%
  map(~{
    suppressWarnings(suppressMessages(st_buffer(
      x = st_union(m[m$state %in% .x, ]),
      dist = 0.0001,
      endCapStyle = "SQUARE"
    )))
  }) -> m_borders

gg <- ggplot()
for (mb in m_borders) {
  gg <- gg + geom_sf(data = mb, col = "#2b2b2b", size = 0.125)
}

gg +
  geom_sf(
    data = gsf,
    aes(fill = candidate),
    col = "white", shape = 22, size = 3, stroke = 0.125
  ) +
  scale_fill_manual(
    name = NULL,
    na.value = "#f0f0f0",
    values = c(
      "Biden" = '#f0027f',
      "Sanders" = '#7fc97f',
      "Warren" = '#beaed4',
      "Buttigieg" = '#fdc086',
      "Klobuchar" = '#ffff99',
      "Gabbard" = '#386cb0',
      "Bloomberg" = '#bf5b17'
    ),
    limits = intersect(unique(delegates$candidate), names(delegates_pal))
  ) +
  guides(
    fill = guide_legend(
      override.aes = list(size = 4)
    )
  ) +
  coord_sf(datum = NA) +
  theme_ipsum_es(grid="") +
  theme(legend.position = "bottom")

{ssdeepr}

Researcher pals over at Binary Edge added web page hashing (pre- and post-javascript scraping) to their platform using ssdeep. This approach is in the category of context triggered piecewise hashes (CTPH) (or local sensitivity hashing) similar to my R adaptation/packaging of Trend Micro’s tlsh.

Since I’ll be working with BE’s data off-and-on and the ssdeep project has a well-crafted library (plus we might add ssdeep support at $DAYJOB), I went ahead and packaged that up as well.

I recommend using the hash_con() function if you need to read large blobs since it doesn’t require you to read everything into memory first (though hash_file() doesn’t either, but that’s a direct low-level call to the underlying ssdeep library file reader and not as flexible as R connections are).

These types of hashes are great at seeing if something has changed on a website (or see how similar two things are to each other). For instance, how closely do CRAN mirror match the mothership?

library(ssdeepr) # see the links above for installation

cran1 <- hash_con(url("https://cran.r-project.org/web/packages/available_packages_by_date.html"))
cran2 <- hash_con(url("https://cran.biotools.fr/web/packages/available_packages_by_date.html"))
cran3 <- hash_con(url("https://cran.rstudio.org/web/packages/available_packages_by_date.html"))

hash_compare(cran1, cran2)
## [1] 0

hash_compare(cran1, cran3)
## [1] 94

I picked on cran.biotools.fr as I saw they were well-behind CRAN-proper on the monitoring page.

I noted that BE was doing pre- and post-javascript hashing as well. Why, you may ask? Well, websites behave differently with javascript running, plus they can behave differently when different user-agents are set. Let’s grab a page from Wikipedia a few different ways to show how they are not alike at all, depending on the retrieval context. First, let’s grab some web content!

library(httr)
library(ssdeepr)
library(splashr)

# regular grab
h1 <- hash_con(url("https://en.wikipedia.org/wiki/Donald_Knuth"))

# you need Splash running for javascript-enabled scraping this way
sp <- splash(host = "mysplashhost", user = "splashuser", pass = "splashpass")

# js-enabled with one ua
sp %>%
  splash_user_agent(ua_macos_chrome) %>%
  splash_go("https://en.wikipedia.org/wiki/Donald_Knuth") %>%
  splash_wait(2) %>%
  splash_html(raw_html = TRUE) -> js1

# js-enabled with another ua
sp %>%
  splash_user_agent(ua_ios_safari) %>%
  splash_go("https://en.wikipedia.org/wiki/Donald_Knuth") %>%
  splash_wait(2) %>%
  splash_html(raw_html = TRUE) -> js2

h2 <- hash_raw(js1)
h3 <- hash_raw(js2)

# same way {rvest} does it
res <- httr::GET("https://en.wikipedia.org/wiki/Donald_Knuth")

h4 <- hash_raw(content(res, as = "raw"))

Now, let’s compare them:

hash_compare(h1, h4) # {ssdeepr} built-in vs httr::GET() => not surprising that they're equal
## [1] 100

# things look way different with js-enabled

hash_compare(h1, h2)
## [1] 0
hash_compare(h1, h3)
## [1] 0

# and with variations between user-agents

hash_compare(h2, h3)
## [1] 0

hash_compare(h2, h4)
## [1] 0

# only doing this for completeness

hash_compare(h3, h4)
## [1] 0

For this example, just content size would have been enough to tell the difference (mostly, note how the hashes are equal despite more characters coming back with the {httr} method):

length(js1)
## [1] 432914

length(js2)
## [1] 270538

nchar(
  paste0(
    readLines(url("https://en.wikipedia.org/wiki/Donald_Knuth")),
    collapse = "\n"
  )
)
## [1] 373078

length(content(res, as = "raw"))
## [1] 374099

FIN

If you were in a U.S. state with a primary yesterday and were eligible to vote (and had something to vote for, either a (D) candidate or a state/local bit of business) I sure hope you did!

The ssdeep library works on Windows, so I’ll be figuring out how to get that going in {ssdeepr} fairly soon (mostly to try out the Rtools 4.0 toolchain vs deliberately wanting to support legacy platforms).

As usual, drop issues/PRs/feature requests where you’re comfortable for any of these or other packages.

For folks who are smart enough not to go near Twitter, I’ve been on a hiatus from the platform insofar as reading the Twitter feed goes. “Why” isn’t the subject of this post so I won’t go into it, but I’ve broken this half-NYE resolution on more than one occasion and am very glad I did so late January when I caught a RT of this tweet by WSJ’s Brian McGill:

You guys! I spent 2 days making a cartogram by hand with 3,979 freaking squares on it. One for each delegate to the Democratic National Convention. Never doing it again.* Apologies to Georgia, you got the short end of the stick shape-wise.
.
.
.
.
*absolutely going to to it again pic.twitter.com/1qIgUw1oIc

— Brian McGill (@brian_mcgill) January 29, 2020

You can find it here, and a static copy of a recent one is below:

I kinda wanted to try to make a woefully imperfect static version of it in R with {ggplot2} so poked around at that URL’s XHR objects and javascript to see if I could find the cartogram and the data source.

The data source was easy as it’s an XHR loaded JSON file: https://asset.wsj.net/wsjnewsgraphics/election/2020/delegates.json.

The cartogram bits… were not. Brian’s two-days of manual effort still needed to be put into something that goes onto a web page and news outlets are super-talented at making compact, fast-loading interactive visualizations, which means one tool they use is “webpack”-esque tools to combine many small javascript files into one. I did traipse through it seeing if there as a back-end JSON or CSV somewhere but could not locate it. However, their cartogram library builds the SVG you see on the page. If you use Developer Tools to inspect any element of the SVG then copy the whole SVG “outer HTML” and save it to a local file:

After using an intercept proxy, it turns out this is a dynamically loaded resource, too: https://asset.wsj.net/wsjnewsgraphics/election/delegate-tracker/carto.svg.

That SVG has three top layer groups and has some wicked transforms in it. There was no way I was going to attempt a {statebins}-esque approach to this copycat project (i.e. convert the squares to a grid and map things manually like Brian did) but I had an idea and used Adobe Illustrator to remove the state names layer and the background polygon layer, then “flatten” the image (which — to over-simplify the explanation — flattens all the transforms), and save it back out.

Then, I added a some magic metadata prescribed by svg2geojson to turn the SVG into a GeoJSON file (which {sf} can read!). (That sentence just made real cartographers & geocomp’ers weep, btw).

Now, that I had something R could use in a bit of an easier fashion there was still work to be done. The SVG 1-px <rect> elements ended up coming across as POLYGONs and many, many more point-squares came along for the ride (in retrospect, I think they may have been the borders around the states, more on that in a bit).

I used {purrr} and {st_coordinates} to figure out where all the 1-px “polygons” were in the {sf} object and isolated them, then added an index field (1:n, n being the number of delegate squares for a given state).

I read in the original SVG with {xml2} and extracted the named state groups. Thankfully the order and number of “blocks” matched the filtered {sf} object. I merged them together, turned the 1-px POLYGONs into POINTs, and made the final {sf} object which I put in the nascent {catchpole} package (location below). Here’s a quick view of it using plot():

library(catchpole) # hrbrmstr/catchpole

plot(delegates_map()[1])

delegates_map()
## Simple feature collection with 3979 features and 2 fields
## geometry type:  POINT
## dimension:      XY
## bbox:           xmin: -121.9723 ymin: 37.36802 xmax: -121.9581 ymax: 37.37453
## epsg (SRID):    4326
## proj4string:    +proj=longlat +datum=WGS84 +no_defs
## First 10 features:
##    state idx                   geometry
## 1     WY   1 POINT (-121.9693 37.37221)
## 2     WY   2 POINT (-121.9693 37.37212)
## 3     WY   3 POINT (-121.9691 37.37221)
## 4     WY   4 POINT (-121.9691 37.37212)
## 5     WY   5 POINT (-121.9691 37.37203)
## 6     WY   6 POINT (-121.9691 37.37194)
## 7     WY   7 POINT (-121.9691 37.37185)
## 8     WY   8  POINT (-121.969 37.37221)
## 9     WY   9  POINT (-121.969 37.37212)
## 10    WY  10  POINT (-121.969 37.37203)

All that was needed was to try it out with the real data.

I simplified that process quite a bit in {catchpole} but also made it possible to work with the individual bits on your own. {gg_catchpole()} will fetch the WSJ delegate JSON and build the basic map for you using my dark “ipsum” theme:

library(sf)
library(catchpole) # hrbrmstr/catchpole
library(hrbrthemes)
library(tidyverse)

gg_catchpole() +
  theme_ft_rc(grid="") +
  theme(legend.position = "bottom")

BONUS!

Now that you have the WSJ JSON file, you can do other, basic visualizations with it:

library(hrbrthemes)
library(waffle)
library(geofacet)
library(tidyverse)

jsonlite::fromJSON(
  url("https://asset.wsj.net/wsjnewsgraphics/election/2020/delegates.json"),
  simplifyDataFrame = FALSE
) -> del

c(
  "Biden" = "#5ac4c2",
  "Sanders" = "#63bc51",
  "Warren" = "#9574ae",
  "Buttigieg" = "#007bb1",
  "Klobuchar" = "#af973a",
  "Bloomberg" = "#AA4671",
  "Steyer" = "#4E4EAA",
  "Yang" = "#C76C48",
  "Gabbard" = "#7B8097"
) -> dcols

bind_cols(del$data$US$delCount) %>%
  gather(candidate, delegates) %>%
  filter(delegates > 0) %>%
  arrange(desc(delegates)) %>%
  mutate(candidate = fct_inorder(candidate)) %>%
  ggplot(aes(candidate, delegates)) +
  geom_col(fill = ggthemes::tableau_color_pal()(1), width = 0.55) +
  labs(
    x = NULL, y = "# Delegates",
    title = "2020 Democrat POTUS Race Delegate Counts",
    subtitle = sprintf("Date: %s", Sys.Date()),
    caption = "Data source: WSJ <https://asset.wsj.net/wsjnewsgraphics/election/2020/delegates.json>\n@hrbrmstr #rstats"
  ) +
  theme_ipsum_rc(grid="Y")

bind_cols(del$data$US$delCount) %>%
  gather(candidate, delegates) %>%
  filter(delegates > 0) %>%
  arrange(desc(delegates)) %>%
  mutate(candidate = fct_inorder(candidate)) %>%
  ggplot(aes(fill=candidate, values=delegates)) +
  geom_waffle(color = "white", size = 0.5) +
  scale_fill_manual(name = NULL, values = dcols) +
  coord_fixed() +
  labs(
    x = NULL, y = "# Delegates",
    title = "2020 Democrat POTUS Race Delegate Counts",
    subtitle = sprintf("Date: %s", Sys.Date()),
    caption = "Data source: WSJ <https://asset.wsj.net/wsjnewsgraphics/election/2020/delegates.json>\n@hrbrmstr #rstats"
  ) +
  theme_ipsum_rc(grid="") +
  theme_enhance_waffle()

state_del <- del
state_del$data[["US"]] <- NULL

map_df(state_del$data, ~bind_cols(.x$delCount), .id = "state") %>%
  gather(candidate, delegates, -state) %>%
  filter(delegates > 0) %>%
  ggplot(aes(candidate, delegates)) +
  geom_col(aes(fill = candidate), col = NA, width = 0.55) +
  scale_fill_manual(name = NULL, values = dcols) +
  facet_geo(~state) +
  labs(
    x = NULL, y = "# Delegates",
    title = "2020 Democrat POTUS Race Delegate Counts by State",
    subtitle = sprintf("Date: %s", Sys.Date()),
    caption = "Data source: WSJ <https://asset.wsj.net/wsjnewsgraphics/election/2020/delegates.json>\n@hrbrmstr #rstats"
  ) +
  theme_ipsum_rc(grid="Y") +
  theme(axis.text.x = element_blank()) +
  theme(panel.spacing.x = unit(0.5, "lines")) +
  theme(panel.spacing.y = unit(0.1, "lines")) +
  theme(legend.position = c(0.95, 0.1)) +
  theme(legend.justification = c(1, 0))

FIN

More work needs to be done on the map and {catchpole} itself but there’s a sufficient base for others to experiment with (PRs and your own blog posts welcome!).

W/r/t “more on that later” bits: The extra polygons were very likely borders and I think borders would help the cartogram, but we can make them with {sf}, too. We can also add in a layer for state names and/or just figure out the centroid for each point grouping (with {sf}) and get places for labels that way). Not sure I’ll have time for any of that (this whole process went quickly, believe it or not).

Also: ggiraph::geom_sf_interactive() can be used as a poor-dude’s popup to turn this (quickly) into an interactive piece.

If you hit up https://git.rud.is/hrbrmstr/catchpole you’ll find the package and URLs to other social coding sites (though GitUgh has been plagued with downtime and degraded performance the past few weeks so you should really think about moving your workloads to real service).

Have fun mapping Über Tuesday and share your creations, PR’s, ideas, etc for the package wherever you’re most comfortable.
